05 MENU OPERATIONS
44
4K/UHD 12G-Quad Multi View Monitor
[7] WAVEFORM & FOCUS
Waveform & Focus
WAVE FORM DISPLAY
WAVE FORM INTENSITY
WAVE FORM TRANS.
WAVE FORM COLOR
LINE WAVE FORM
SELECT LINE POSITION
LUMA ( Y’ ) ZONE CHECK
LUMA ( Y’ ) ZONE ADJUST
FOCUS ASSIST
FOCUS ASSIST COLOR
FOCUS ASSIST LEVEL
RANGE ERROR
Y MAX
Y MIN
C MAX
C MAX
BLINK
COLOR
GRID
LXM-180P
OFF
BLACK
OFF
4
0
50
0
254
0
254
0
WAVEFORM OFF
OPAQUE
GREEN
OFF
OFF
OFF
RED
OFF
● FOCUS ASSIST COLOR
- Select a color for Focus Assist.
- Selectable mode: [RED], [BLUE], [WHITE],
[VIOLET]
● FOCUS ASSIST LEVEL
- Set the edge dierence value between the
edges in an image.
- Adjustable level: [0] to [100] (Increments of 1)
The larger value means the more sophisticated
detail detection.
- The designated color is displayed on the
boundaries when the dierence of the
edges exceeds the previously set value.
- This feature is available only when the
[FOCUS ASSIST] mode is activated.
● FOCUS ASSIST
- This function helps the shooters to easily nd
out the exact area in the picture with good
focus, simply by adding colors on the shape or
boundaries of the object in the picture.
- [COLOR ON]: Only the boudary of the area
with good focus is displayed with the
designated color.
- [MONO ON]: The image is displayed in black
and white, and the boundary of the area with
good focus is colored with the designated color.
<FOCUS ASSIST - COLOR ON>
<FOCUS ASSIST - MONO ON>
