05 MENU OPERATIONS
35
4K/UHD 12G-Quad Multi View Monitor
[4] GPI
GPI 3/3
LXM-180P
CHANNEL 4
MONITOR ID
UMD CHARACTER
UMD CHAR . COLOR
8
CHANNEL 4
GREEN
CHANNEL 3
MONITOR ID
UMD CHARACTER
UMD CHAR . COLOR
0
CHANNEL 3
BLACK
CHANNEL 2
MONITOR ID
UMD CHARACTER
UMD CHAR . COLOR
2
CHANNEL 2
BLACK
● MONITOR ID
- Set the ID of each monitor when you control
monitors with TVLogic control protocol using
RS-422/485 communication or Network or
when you set and use Dynamic UMD mode in
[UMD DISPLAY] menu.
- Selectable mode: [0] to [124]
● UMD CHARACTER
- Set the characters to be displayed on the UMD.
- Available characters are lowercase and uppercase
alphabet letters, numbers, and special symbols.
● UMD CHAR. COLOR (UMD Character Color)
- Set the character color of UMD.
- Selectable mode: [BLACK], [WHITE], [RED],
[GREEN], [BLUE], [YELLOW], [CYAN], [MAGENTA]
Note
- In Quad-View mode and Picture-by-Picture
mode, make sure to assign the dierent ID
number to each channel.
