05 MENU OPERATIONS
30
4K/UHD 12G-Quad Multi View Monitor
[3] COLOR
Default Values
● VIDEO RANGE
- Select the video range of the input signal.
- Selectable mode: [Narrow (64-940)],
[Narrow109 (64-1019)], [Full (0-1023)]
Note
- The dierent Color settings can be adjusted
for each input video: SDI-1, SDI-2, SDI-3,
SDI-4, HDMI, SFP-1, SFP-2.
The Color settings adjusted for each input
video are maintained even after the monitor
turns o and on.
● Color Save
- Save the changed setting values from
[USER 1] to [USER 10].
- Saving range is from [Color Std (Load)] to
[VIDEO RANGE]
● Color Default
- Return the changed settings from
[Color Space] to [VIDEO RANGE] to the
default values.
Color
Color Std(Load)
Color Space
EOTF
COLOR Temp.
GAIN RED
GAIN GREEN
GAIN BLUE
BIAS RED
BIAS GREEN
BIAS BLUE
BRIGHTNESS
CONTRAST
CHROMA
BACK LIGHT
VIDEO RANGE
Color Save
Color Default
Color Std Mode
LXM-180P
MANUAL
HD
BT . 709
2 . 4
6500K
Narrow109 (64-1019)
Save
Default
0
0
0
0
0
0
0
0
0
16
Color Standard Color Space EOTF COLOR Temp. Video Range
HD BT.709 2.4 6500K Narrow109 (64~1019)
UHD BT.2020 2.4 6500K Narrow109 (64~1019)
DCI DCI-P3 2.6 6500K Full (0~1023)
PQ BT.2020 PQ(ST-2084) 6500K Narrow (64-940)
PQ-P3 DCI-P3 PQ(ST-2084) 6500K Full (0~1023)
HLG BT.2020 HLG 6500K Narrow (64-940)
*Default Values
