05 MENU OPERATIONS
43
4K/UHD 12G-Quad Multi View Monitor
[7] WAVEFORM & FOCUS
Waveform & Focus
WAVE FORM DISPLAY
WAVE FORM INTENSITY
WAVE FORM TRANS.
WAVE FORM COLOR
LINE WAVE FORM
SELECT LINE POSITION
LUMA ( Y’ ) ZONE CHECK
LUMA ( Y’ ) ZONE ADJUST
FOCUS ASSIST
FOCUS ASSIST COLOR
FOCUS ASSIST LEVEL
RANGE ERROR
Y MAX
Y MIN
C MAX
C MAX
BLINK
COLOR
GRID
LXM-180P
OFF
BLACK
OFF
4
0
50
0
254
0
254
0
WAVEFORM OFF
OPAQUE
GREEN
OFF
OFF
OFF
RED
OFF
● LUMA(Y') ZONE CHECK (To be supported)
- Analyze the Luma(Y’) level of the input
image and displays the selected zone on
the screen.
- Selectable mode: [Color Patt. ON],
[Zebra Patt. ON]
- After each pixel’s Y’ level is analyzed, it is
displayed as a certain color or zebra pattern
according to the Index on the right side of
the screen.
- When a pixel’s Y’ level is under 0%(16), the
pixel is displayed as green color or green
diagonal lines, and over 100%(235) as red
color or red diagonal lines.
- When the Y’ level of a pixel is between
0~100%, the pixel is displayed as Gray level,
except for selected Luma Zone.
- In the [Color Pattern] mode, the zone the
user adjusted is displayed as Yellow
(10% lower zone), Pink (±2.5%), Cyan
(10% upper zone).
- In the [Zebra Pattern] mode, ±5% of the
selected Y’ Level will be displayed as
diagonal lines.
*For more information on this function, refer
to "06 FUNCTION DETAILS [5] LUMA(Y')
ZONE CHECK" in page 57.
● LUMA ZONE ADJUST
- Set the Y’ level to be colored Yellow, Pink
and Cyan in [Color Patt. ON] mode, or to set
Y’ level zone to be displayed with diagonal
lines in [Zebra Patt. ON] mode simply by
scrolling with the ENTER knob.
- Selectable range: [0]% to [100]%
(Increments of 1)
● SELECT LINE POSITION
- Select the specic horizontal line for Waveform
and Vector Scope.
- This menu is available when [LINE WAVEFORM]
is activated.
- The adjustable range varies according to the
resolution of the input signal. (SDI signal)
• PAL: Min. 1, Max. 625
• NTSC: Min. 1, Max. 525
• 720p: Min. 1, Max. 750
• 1080i: Min. 1, Max. 1125
• 1080p: Min. 1, Max. 1125
• 2160p: Min. 1, Max. 1125
