42 tvONE

These are grouped together into their associated on-screen menus.

Your unit and this manual should be used to determine the actual function of each of the following, as

only the menu text is listed here. Where an equivalent menu item does not exist on your unit, then that

feature is not supported on.

Function codes are given in hexadecimal and adjustment range is in decimal (but always sent as

hexadecimal!).

For dual-channel units the mode of operation also restricts what Window and Output can be used the

following table shows the allowed combinations:

Mode

Allowed Window and Output combinations

Switcher

Output 1 (0x00) and Window A (0x41) / Z (0x5A) / Logo a (0x61)

Independent

Output 1 (0x00) and Window A (0x41) / Z (0x5A) / Logo a (0x61)

OR

Output 2 (0x01) and Window B (0x42) / Z (0x5A) / Logo b (0x62)

Dual PIP

Any combination of Output and Window

The following table is a list of all menu functions, their related function number and valid range of

adjustment.

Note: that not all items will be available on all units. If your unit does not show the menu text in the

menus then that function is not supported.

Menu text

CHA

FUNC

(Hex)

Range of adjustment (decimal)

Top level

Mode

(Dual-channel units only)

109

0 = Switcher

1 = Independent

2 = Dual PIP

Preset number

225

1 to 10

Preset load

226

Set to 1 to load – automatically resets to 0.

Preset store

227

Set to 1 to store – automatically resets to 0.

Preset erase

228

Set to 1 to erase – automatically resets to 0.

Adjust outputs

Output enable

170

0=Blanked, 1=Active

Lock source (connector)

149

0x10 to 0x1F = RGB1 to RGB16

0x30 to 0x3F = CV1 to CV16

0x40 to 0x4F = YC1 to YC16

0x50 to 0x5F = SDI1 to SDI16

0xD0 = OUT1, 0xD1 = OUT2

0xF0 = TC1, 0xF1 = TC2

Lock H Shift

14A

-4096..4096
