MNL- C2-6204-V3.00 35
Sync can be either negative polarity or positive polarity. To further complicate things, it is possible that
you may want to make the Horizontal Sync polarity different from the Vertical Polarity. This control allows
you to make that change. You have four possible selections:
+H+V
-H+V
+H-V
-H-V
The system menu
The final Sub Menu is for adjustments of System parameters. “System” in this case means the unit’s
functions that are generally unrelated to individual inputs, outputs or any of the various production
features.
This screen is an informational screen. Should you require technical assistance with your unit, the
technical support personnel may request that you read the contents of this screen to them during the
support call.
The first section, “SW”, is the version of the software that is installed on your unit. You can update
software via the User Support web site (procedure to be described later in this manual) and the updates
are currently free of charge. “PT” refers to Product Type and “BT” means Board Type. Both of these are
hardware designators and cannot be changed by the user however both designators are important to
support personnel.
This is an information page showing when the currently installed software was released. The information
is useful to the user as he or she compares the date to the website information describing the current
software release.
Normally, the user will examine the added features of each new software release and determine if an
update is worth doing in their particular operation. The greater period of time between the current date,
and the date shown for the currently installed software, the greater the likelihood that there are useful
changes and improvements present in the new release.
The TAC number is a unique identifier for the unit and is for use with the PPF value below.
800 x 600 60 Hz
Sync polarity [+H+V]
System
SW: 16, PT: 12, BT: 13
System
SW date: 2006-7-11
System
TAC# 27-AA-1C-93-F8-33
