MNL- C2-6204-V3.00 27
This menu item lets you adjust the individual RGB or YUV/YPbPr signals, in case one component is at a
different contrast to other, or if they all need to be boosted or lowered.
CV & YC source menu items
Of the above Source Menu items, the Autoset sense and Autoset status functions, RGB type and Pixel
phase are specific to RGB signals only. The rest of the Source menu items function with RGB, CV or YC type
signals. In addition, there are four additional Menu items that are only used with CV or YC type signals
and these are explained below:
Adjust the Brightness and Contrast of the image to your requirement.
Saturation is the amount of color present in the image. Hue is the color “tint” parameter and the
adjustment range is +90 degrees through to -90 degrees with 0 being the default.
Within limits, you can enhance or soften the appearance of detail within an image. The Sharpness values
go both negative and positive, with 0 being the default. Note that over-enhancing an image has the side
effect of making it appear to be noisy and under-enhancing an image gives the appearance of poor video
quality.
On occasion, a video source will have the color portion of the signal offset from the luminance portion. If
you’ve ever seen a poor quality comic book that has the outline of the cartoon character’s head in one
place on the page but the flesh tones for the head offset slightly, you are seeing the print equivalent of
Luminance to Chrominance Phase Delay.
Fortunately, your unit provides a way for you to make the two signals occur at the same time on the
selected image. The adjustment range provides both positive and negative levels of delay with 0 being the
default.
Still image store / testcard source menu items
This item is only available for units supporting Still Image Stores (SIS) or Testcards (TC) – which are the
same thing, but may be named differently depending on your unit.
Used to select the image from memory to use as a source for the SIS / TC source currently selected.
Dedicated software can be used to upload user-defined images – see our website.
Source: YC1
Bright [100] Contrast [100]
Source: YC1
Satur [100] Hue [0]
Source: YC1
Sharpness [0]
Source: YC1
Luma delay [ 0]
Source : TC1
Testcard [ 0]
