22 tvONE
Selection of a CV/YC source will reveal different menu items that allow adjustments beyond those used for
RGB sources. The menu discussions that follow relate first to RGB sources, then to CV / YC type sources.
Menu items common to all inputs
This menu item will be used to correct the aspect ratio of the video source when converted into the final
output resolution. The following table details what happens in the available modes:
Setting
Result
Fill
(default)
The source is stretched to fill the output.
Aspect
The source’s aspect ratio is maintained on the output.
H-fit
The source is stretched to fill the horizontal dimension of the output, with the vertical
dimension stretched by the same amount (and possibly clipped).
V-fit
The source is stretched to fill the vertical dimension of the output, with the horizontal
dimension stretched by the same amount (and possibly clipped).
1:1
Each source pixel is represented by a single output pixel – no scaling will be performed. If
the input resolution is higher than the output, then only part of the source will be seen. If
the input resolution is lower than the output, then a black border will be present.
This menu item allows manual positioning of the Top and Left portion of the image. It is used to ensure
that the input signal is captured correctly, eliminating any black borders. These settings are often used to
correct the position of a PC signal on an input, or to eliminate any undesired noise at the top or bottom of
a PAL or NTSC video source.
This menu item allows manual positioning of the Bottom and Right portion of the image. These settings
are often used to correct the position of a PC signal on an input, or to eliminate any undesired noise at the
top or bottom of a PAL or NTSC video source.
If your unit has an internal audio switcher / selector, this menu item selects the desired Audio input for
use with the active video source, allowing an audio-follow-video function.
If an external audio switcher is connected via the OPTION bus, then this menu item selects the desired
Audio input for use with the active video source, allowing an audio-follow-video function.
Source: RGB1
Aspect correct [ Fill]
Source: RGB1
TL pos. adj. [ 0] [ 0]
Source: RGB1
BR size adj. [ 0] [ 0]
Source: RGB1
Audio input source [ 1]
Source: RGB1
OPTION audio source [ 1]
