support@turbro.com www.turbro.com
05
INSTALLATION INSTRUCTIONS
Installation Location
● The air conditioner should be placed on a firm floor to minimize noise and vibration. For safe and secure
positioning, place the unit on a smooth, level floor strong enough to support the unit.
● The unit must be installed near a properly rated grounded socket.
● Allow at least 19.7 inches / 50 cm of space away from the wall with the window for efficient working. The
height from the exhaust hose to the floor is 35.5 inches(90 cm).
● Never place any obstacles around the air inlet or outlet of the unit.
● The hose can be compressed or extended moderately, but it is desirable to keep the length to a minimum.
Also make sure the hose does not have any sharp bends or sags. See the image below.
Tool Suggested (Not Included in package)
The window panel kit has been designed to fit most standard windows that open vertically or horizontally;
however, it may be necessary for you to improvise/modify some aspect of the installation procedures for
certain types of window.
Minimum and maximum window openings: 11 - 67 Inches
NOTE: If the width of your window is smaller than 25.6 inches, please remove the adjustment panel and then
cut the window panel to make the width of the window panel the same width as your window.
Remember to measure twice and cut once so you don’t cut it too short.
Min 90cm/35.5in
