17-2. TIDC-91 Decomposition Assembly Drawing Component
Q'TY
91W
1 P0106S0100 BRACKET HINGE*L SUS-304 t1.5 1
2 P0106S0200 BRACKET HINGE*R SUS-304 t1.5 1
3 P0106S0300 BRACKET HINGE*M SUS-304 t1.5 1
4 P0114S0100 COVER LAMP*L*R EGI t0.8 2
5 P0106S0400 BRACKET BODY 4
6 P0129S0100 HINGE DOOR*L*R MSWR 2
7 P0129S0200 HINGE DOOR AL 2
8 P0149S0100 INSERT POLE MSWR 3
9 P0114S1900 COVER LAMP WIRE EGI t0.6 1
10 P0145S0100 PLATE MAGNET GRILL SPG t0.6 4
11 P0103S0200 BASE COMP SPG t1.6 2
12 P0106S1000 BRACKET COMP BASE SPG t2.0 2
13 P0100S0400 ASSY FRAME MECH 1
14 P0106S1200 BRK FRAME MECA SPG t2.0 1
15 P0106S0700 BRACKET GRILL SPG t1.0 2
16 P0106S0800 BRACKET GRILL*M EGI t1.0 1
17 P0106S1300 CASE PCB SPG t0.8 1
18 P0124S0400 GRILL PLATE*A (16CAN) EGI t0.6 3
19 P0124S0500 GRILL PLATE*B (16CAN) EGI t0.6 3
20 P0106S1900 BRACKET TIMER SPG t1.0 1
21 P0114S2000 COVER TIMER SPG t0.6 1
22 P0175S0100 HANDLE PAD MAGNET SUS304 t0.8*154 3
23 P0175S0200 HANDLE PAD MAGNET SUS304 t0.8*230 3
24 P0122S2200 FRAME WINDOW*L AL 1
25 P0122S2300 FRAME WINDOW*R AL 1
26 P0122S2700 FRAME WINDOW*B AL 63.5*2279 1
27 P0126S0200 HANDLE DOOR AL W*1080 2
28 P0122S2900 FRAME DOOR AL W*1080 2
29 P0122S3300 FRAME BODY*B AL W*2285 1
30 P0111S0500 CASE LAMP AL W*2282.6 1
31 P0153S0100 POLE SUPPORT*L AL W*382.5 1
32 P0153S0100 POLE SUPPORT*R AL W*382.5 1
33 P0153S0200 POLE SUPPORT*M AL W*382.5 1
34 P0123S0400 GASKET DOOR PVC W*2278 1
35 P0123S0500 GASKET DOOR*S*L*R PVC W*382 4
36 P0123S0700 GASKET HANDLE PVC W*1084 2
37 P0123S0900 GASKET WINDOW*S*L*R PVC W*280 2
38 P0123S1400 GASKET WINDOW*U PVC W*2262 1
39 P0152S0100 STOPPER DOOR*L*R RUBBER 4
40 P0107S0200 BUSHING CAN COVER RUBBER 32
41 P0114S2000 COVER FRAME WIN*L RUBBER 1
42 P0114S2100 COVER FRAME WIN*R RUBBER 1
43 P0141S1400 PAD MAGNET*F M.P 154*1090 2
44 P0141S2000 PAD MAGNET*B M.P 230*1090 2
45 P0141S1500 PAD MAGNET*L M.P 230*526.5 1
46 P0141S1600 PAD MAGNET*R M.P 230*526.5 1
47 P0114S2200 CAN COVER ABS 16
48 P0130S0100 HOLDER GRILL PLT*L NYLON 6 2
49 P0130S0200 HOLDER GRILL PLT*R NYLON 6 2
50 P0117S0200 DOOR PC t4.5 2
51 P0114S2300 COOLING COVER ABS t2.0 4
52 P0155S0400 WINDOW GLASE t6.0 1
53 P0155S0500 WINDOW*S*L*R GLASE t6.0 2
54 P0178S0100 WIRE RACK*A WIRE 16
55 P0178S0200 FRAME-RACK " 4
56 P0138S0200 ASSY LED LAMP LED BAR 910 2
57 P0185S0400 POWER SUPPLY (SMPS) LPV-35-24 1
58 P0100S0600 CONDENSER 4 LINE 10 COLUMN 2
59 P0144S1300 PIPE SUCTION ( 47,70,91W ) 2
60 P0100S0700 SUB-CONDENSER ø4.76*ø200 1
61 P0168S0100 DRYER DML 032S 2
62 P0199S0100 TIMER T38N-03A 1
63 P0186S0100 RELAY GMC-30P2 110V 1
64 30218B0300 FAN RADI ø200 (SUCTION) 2
65 3.021E+09 BRACKET SUBORT (A) 2
66 PO109S0100 CAP DRAIN PA-6 1
67 30275U0200 MAG STOPPER GRILL PLT 4
68 30206A4600 BRACKET MAGNET 4
69 30200Q1200 SAMSUNG COMPRESSOR SK1A1C-L2W 115V 1
70 30200R1100 FRANCE COMPRESSOR CAE2420Z 115V 1
71 3.963E+09 MOTOR SHADED POLE IS-4420DWSG-1 2
72 4VMOA15630 CUSH FAN-MOTOR FIXR 4
73 30213A1014 POWER CORD 1
74 30281Q0101 S/W LAMP 1
75 30283N0100 THERMOSTAT GNF-107DC
1
76 P0127S0100 COMP WIRE 2P (FRANCE COMP)
1
77 P0127S0200 COMP WIRE 4P (SAMSUNG COMP)
1
NO
PART CODE
PART NAME
DESCRIPTION
