16-2. TIDC-70 Decomposition Assembly Drawing Component
Q'TY
70W
1 P0106S0100 BRACKET HINGE*L SUS-304 t1.5
1
2 P0106S0200 BRACKET HINGE*R SUS-304 t1.5
1
3 P0106S0300 BRACKET HINGE*M SUS-304 t1.5
1
4 P0114S0100 COVER LAMP*L*R EGI t0.8
2
5 P0106S0400 BRACKET BODY
4
6 P0129S0100 HINGE DOOR*L*R MSWR
2
7 P0129S0200 HINGE DOOR AL
2
8 P0149S0100 INSERT POLE MSWR
3
9 P0114S1900 COVER LAMP WIRE EGI t0.6
1
10 P0145S0100 PLATE MAGNET GRILL SPG t0.6
4
11 P0103S0200 BASE COMP SPG t1.6
2
12 P0106S1000 BRACKET COMP BASE SPG t2.0
2
13 P0100S0300 ASSY FRAME MECH
1
14 P0106S1200 BRK FRAME MECA SPG t2.0
1
15 P0106S0700 BRACKET GRILL SPG t1.0
2
16 P0106S0800 BRACKET GRILL*M EGI t1.0
1
17 P0106S1300 CASE PCB SPG t0.8
1
18 P0124S0300 GRILL PLATE A (12CAN) EGI t0.6
6
19 P0106S1900 BRACKET TIMER SPG t1.0
1
20 P0114S2000 COVER TIMER SPG t0.6
1
21 P0175S0100 HANDLE PAD MAGNET SUS304 t0.8*154
3
22 P0175S0200 HANDLE PAD MAGNET SUS304 t0.8*230
3
23 P0122S2200 FRAME WINDOW*L AL
1
24 P0122S2300 FRAME WINDOW*R AL
1
25 P0122S2600 FRAME WINDOW*B AL 63.5*1747
1
26 P0126S0100 HANDLE DOOR AL W*548
1
27 P0126S0200 HANDLE DOOR AL W*1080
1
28 P0122S2800 FRAME DOOR AL W*548
1
29 P0122S2900 FRAME DOOR AL W*1080
1
30 P0122S3200 FRAME BODY*B AL W*1753
1
31 P0111S0400 CASE LAMP AL W*1750.6
1
32 P0153S0100 POLE SUPPORT*L AL W*382.5
1
33 P0153S0100 POLE SUPPORT*R AL W*382.5
1
34 P0153S0200 POLE SUPPORT*M AL W*382.5
1
35 P0123S0300 GASKET DOOR PVC W*1746
1
36 P0123S0500 GASKET DOOR*S*L*R PVC W*382
4
37 P0123S0600 GASKET HANDLE PVC W*552
1
38 P0123S0700 GASKET HANDLE PVC W*1084
1
39 P0123S0900 GASKET WINDOW*S*L*R PVC W*280
2
40 P0123S1300 GASKET WINDOW*U PVC W*1730
1
41 P0152S0100 STOPPER DOOR*L*R RUBBER
4
42 P0107S0200 BUSHING CAN COVER RUBBER
24
43 P0114S2000 COVER FRAME WIN*L RUBBER
1
44 P0114S2100 COVER FRAME WIN*R RUBBER
1
45 P0141S1300 PAD MAGNET*F M.P 154*825
2
46 P0141S1900 PAD MAGNET*B M.P 230*825
2
47 P0141S1500 PAD MAGNET*L M.P 230*526.5
1
48 P0141S1600 PAD MAGNET*R M.P 230*526.5
1
49 P0114S2200 CAN COVER ABS
12
50 P0130S0100 HOLDER GRILL PLT*L NYLON 6
2
51 P0130S0200 HOLDER GRILL PLT*R NYLON 6
2
52 P0117S0100 DOOR PC t4.5
1
53 P0117S0200 DOOR PC t4.5
1
54 P0114S2300 COOLING COVER ABS t2.0
3
55 P0155S0300 WINDOW GLASE t6.0
1
56 P0155S0500 WINDOW*S*L*R GLASE t6.0
2
57 P0178S0100 WIRE RACK*A WIRE
12
58 P0178S0200 FRAME-RACK " 3
59 P0138S0100 ASSY LED LAMP LED BAR 468
1
60 P0138S0200 ASSY LED LAMP LED BAR 910
1
61 P0185S0300 POWER SUPPLY (SMPS) LPV-35-24
1
62 P0100S0500 CONDENSER 4 LINE 8 COLUMN
1
63 P0100S0600 CONDENSER 4 LINE 10 COLUMN
1
64 P0144S1300 PIPE SUCTION ( 47,70,91W )
2
65 P0100S0700 SUB-CONDENSER
ø4.76*ø200 1
66 P0168S0100 DRYER DML 032S
2
67 P0199S0100 TIMER T38N-03A
1
68 P0186S0100 RELAY GMC-30P2 110V
1
69 30218B0300 FAN RADI
ø200 (SUCTION)
2
70 3.021E+09 BRACKET SUBORT (A)
2
71 PO109S0100 CAP DRAIN PA-6
1
72 30275U0200 MAG STOPPER GRILL PLT
4
73 30206A4600 BRACKET MAGNET
4
74 30200Q1200 SAMSUNG COMPRESSOR SK1A1C-L2W 115V
2
75 3.963E+09 MOTOR SHADED POLE IS-4420DWSG-1
2
76 4VMOA15630 CUSH FAN-MOTOR FIXR
4
77 30213A1014 POWER CORD
1
78 30281Q0101 S/W LAMP
1
79 30283N0100 THERMOSTAT GNF-107DC
1
80 P0127S0200 COMP WIRE 4P (SAMSUNG COMP)
2
NO
PART CODE
PART NAME
DESCRIPTION
