15-2. TIDC-47 Decomposition Assembly Drawing
Component
Q'TY
47W
1 P0106S0100 BRACKET HINGE*L SUS-304 t1.5
1
2 P0106S0200 BRACKET HINGE*R SUS-304 t1.5
1
3 P0114S0100 COVER LAMP*L*R EGI t0.8
2
4 P0106S0400 BRACKET BODY
2
5 P0129S0100 HINGE DOOR*L*R MSWR
2
6 P0129S0200 HINGE DOOR AL
2
7 P0149S0100 INSERT POLE MSWR
2
8 P0114S1900 COVER LAMP WIRE EGI t0.6
1
9 P0145S0100 PLATE MAGNET GRILL SPG t0.6
2
10 P0103S0200 BASE COMP SPG t1.6
1
11 P0106S1000 BRACKET COMP BASE SPG t2.0
1
12 P0100S0200 ASSY FRAME MECH
1
13 P0106S0700 BRACKET GRILL SPG t1.0
1
14 P0111S0100 CASE PCB SPG t0.8
1
15 P0124S0200 GRILL PLATE A (8CAN) EGI t0.6
3
16 P0175S0100 HANDLE PAD MAGNET SUS304 t0.8*154
2
17 P0175S0200 HANDLE PAD MAGNET SUS304 t0.8*230
2
18 P0122S2200 FRAME WINDOW*L AL
1
19 P0122S2300 FRAME WINDOW*R AL
1
20 P0122S2500 FRAME WINDOW*B AL 63.5*1151
1
21 P0126S0200 HANDLE DOOR AL W*1080
1
22 P0122S2900 FRAME DOOR AL W*1080
1
23 P0122S3100 FRAME BODY*B AL W*1158
1
24 P0111S0300 CASE LAMP AL W*1154.6
1
25 P0153S0100 POLE SUPPORT*L AL W*382.5
1
26 P0153S0100 POLE SUPPORT*R AL W*382.5
1
27 P0123S0200 GASKET DOOR PVC W*1150
1
28 P0123S0500 GASKET DOOR*S*L*R PVC W*382
2
29 P0123S0700 GASKET HANDLE PVC W*1084
1
30 P0123S0900 GASKET WINDOW*S*L*R PVC W*280
2
31 P0123S1200 GASKET WINDOW*U PVC W*1134
1
32 P0152S0100 STOPPER DOOR*L*R RUBBER
2
33 P0107S0200 BUSHING CAN COVER RUBBER
16
34 P0114S2000 COVER FRAME WIN*L RUBBER
1
35 P0114S2100 COVER FRAME WIN*R RUBBER
1
36 P0141S1200 PAD MAGNET*F M.P 154*1060
1
37 P0141S1800 PAD MAGNET*B M.P 230*1060
1
38 P0141S1500 PAD MAGNET*L M.P 230*526.5
1
39 P0141S1600 PAD MAGNET*R M.P 230*526.5
1
40 P0114S2200 CAN COVER ABS
8
41 P0130S0100 HOLDER GRILL PLT*L NYLON 6
1
42 P0130S0200 HOLDER GRILL PLT*R NYLON 6
1
43 P0117S0200 DOOR PC t4.5
1
44 P0114S2300 COOLING COVER ABS t2.0
2
45 P0155S0200 WINDOW GLASE t6.0
1
46 P0155S0500 WINDOW*S*L*R GLASE t6.0
2
47 P0178S0100 WIRE RACK*A WIRE
8
48 P0178S0200 FRAME-RACK " 2
49 P0138S0200 ASSY LED LAMP LED BAR 910
1
50 P0185S0100 POWER SUPPLY (SMPS) LPV-20-24
1
51 P0100S0600 CONDENSER 4 LINE 10COLUMN
1
52 P0144S1300 PIPE SUCTION ( 47,70,91W )
1
53 P0100S0700 SUB-CONDENSER
ø4.76*ø200 1
54 P0168S0100 DRYER DML 032S
1
55 30218B0300 FAN RADI
ø200 (SUCTION)
1
56 3.021E+09 BRACKET SUBORT (A)
1
57 PO109S0100 CAP DRAIN PA-6
1
58 30275U0200 MAG STOPPER GRILL PLT
2
59 30206A4600 BRACKET MAGNET
2
60 30200R1100 FRANCE COMPRESSOR CAE2420Z 115V
1
61 3.963E+09 MOTOR SHADED POLE IS-4420DWSG-1
1
62 4VMOA15630 CUSH FAN-MOTOR FIXR
2
63 30213A1014 POWER CORD
1
64 30281Q0101 S/W LAMP
1
65 30283N0100 THERMOSTAT GNF-107DC
1
66 P0127S0100 COMP WIRE 2P (FRANCE COMP)
1
NO
PART CODE
PART NAME
DESCRIPTION
