14-2. TIDC-26 Decomposition Assembly Drawing
Component
Q'TY
26W
1 P0106S0100 BRACKET HINGE*L SUS-304 t1.5 1
2 P0106S0200 BRACKET HINGE*R SUS-304 t1.5 1
3 P0114S0100 COVER LAMP*L*R EGI t0.8 2
4 P0106S0400 BRACKET BODY 2
5 P0129S0100 HINGE DOOR*L*R MSWR 2
6 P0129S0200 HINGE DOOR AL 2
7 P0149S0100 INSERT POLE MSWR 2
8 P0114S1900 COVER LAMP WIRE EGI t0.6 1
9 P0145S0100 PLATE MAGNET GRILL SPG t0.6 2
10 P0103S0100 BASE COMP SPG t1.6 1
11 P0106S0900 BRACKET COMP BASE SPG t2.0 1
12 P0100S0100 ASSY FRAME MECH 1
13 P0111S0100 CASE PCB SPG t0.8 1
14 P0106S1300 BRACKET PCB ASSY SPG t1.6 1
15 P0106S1400 BRACKET PCB CASE SPG t1.0 1
16 P0124S0100 GRILL PLATE A (4CAN) EGI t0.6 3
17 P0175S0100 HANDLE PAD MAGNET SUS304 t0.8*154 2
18 P0175S0200 HANDLE PAD MAGNET SUS304 t0.8*230 2
19 P0122S2200 FRAME WINDOW*L AL 1
20 P0122S2300 FRAME WINDOW*R AL 1
21 P0122S2400 FRAME WINDOW*B AL 63.5*619 1
22 P0126S0100 HANDLE DOOR AL W*548 1
23 P0122S2800 FRAME DOOR AL W*548 1
24 P0122S3000 FRAME BODY*B AL W*626 1
25 P0111S0200 CASE LAMP AL W*622.6 1
26 P0153S0100 POLE SUPPORT*L AL W*382.5 1
27 P0153S0100 POLE SUPPORT*R AL W*382.5 1
28 P0123S0100 GASKET DOOR PVC W*616 1
29 P0123S0500 GASKET DOOR*S*L*R PVC W*382 2
30 P0123S0600 GASKET HANDLE PVC W*552 1
31 P0123S0800 GASKET WINDOW*S*L*R PVC W*280 2
32 P0123S1100 GASKET WINDOW*U PVC W*602 1
33 P0152S0100 STOPPER DOOR*L*R RUBBER 2
34 P0107S0200 BUSHING CAN COVER RUBBER 8
35 P0114S2000 COVER FRAME WIN*L RUBBER 1
36 P0114S2100 COVER FRAME WIN*R RUBBER 1
37 P0141S1100 PAD MAGNET*F M.P 154*530 1
38 P0141S1700 PAD MAGNET*B M.P 230*530 1
39 P0141S1500 PAD MAGNET*L M.P 230*526.5 1
40 P0141S1600 PAD MAGNET*R M.P 230*526.5 1
41 P0114S2200 CAN COVER ABS 4
42 P0130S0100 HOLDER GRILL PLT*L NYLON 6 1
43 P0130S0200 HOLDER GRILL PLT*R NYLON 6 1
44 P0117S0100 DOOR PC t4.5 1
45 P0114S2300 COOLING COVER ABS t2.0 1
46 P0155S0100 WINDOW GLASE t6.0 1
47 P0155S0500 WINDOW*S*L*R GLASE t6.0 2
48 P0178S0100 WIRE RACK*A WIRE 4
49 P0178S0200 FRAME-RACK " 1
50 P0138S0100 ASSY LED LAMP LED BAR 468 1
51 P0185S0100 POWER SUPPLY (SMPS) LPV-20-24 1
52 P0100S0500 CONDENSER 4 LINE 8 COLUMN 1
53 P0144S1200 PIPE SUCTION ( 26W ) 1
54 P0100S0700 SUB-CONDENSER ø4.76*ø200 1
55 P0168S0100 DRYER DML 032S 1
56 30218B0300 FAN RADI ø200 (SUCTION) 1
57 3.021E+09 BRACKET SUBORT (A) 1
58 PO109S0100 CAP DRAIN PA-6 1
59 30275U0200 MAG STOPPER GRILL PLT 2
60 30206A4600 BRACKET MAGNET 2
61 30200Q1200 SAMSUNG COMPRESSOR SK1A1C-L2W 115V 1
62 3.963E+09 MOTOR SHADED POLE IS-4420DWSG-1 1
63 4VMOA15630 CUSH FAN-MOTOR FIXR 2
64 30213A1014 POWER CORD 1
65 30281Q0101 S/W LAMP 1
66 30283N0100 THERMOSTAT GNF-107DC 1
67 P0127S0200 COMP WIRE 4P (SAMSUNG COMP) 1
NO
PART CODE
PART NAME
DESCRIPTION
