66. REPLACEMENT OF WINDOW, WINDOW L,R, POLE SUPPORT
1. RELEASE SCREWS IN THE BLACK CIRCLE BY (+)
DRIVER.
2. DETACHT A HARNESS OF SWITCH.
3. FRAME WINDOW CONSISTS OF WINDOW WITH
[1], [2] AND [5] ATTAHED BY SILICON.
IN ORDER TO DETACH, PULL WINDOW TOWARD
[3] THEN WINDOW WILL BE APART FROM SIDE
WINDOW.
4. DETACH FRAME WINDOW FROM WINDOW BY
PULLING APART TOWARD [4] AND [3].
5. IN ORDER TO ASSEMBLE FRAME WINDOW,
ATTACH FRAME WINDOW TO WINDOW AFTER
SPREADING LITTLE SILICON GLUE ON [1] AND [2].
(IF FRAME WINDOW CAN BE ATTACHED TO
WINDOW DUE TO HARDENED SILICON GLUE, YOU
SHOULD ORDER NOT ONLY FRAME WINDOW BUT
ALSO WINDOW.)
ATTACHING
2
1
3
4
ATTACHING
5
FRAME WINDW
