10
Turbo air
SPECIFICATIONS
Refrigerators
Model
Rating
Temp.
(
℉
)
Operating
Temp.
(
℉
)
Equipment
Class
Designation
V/Hz Refrigerant AMPS
TGM-5SD*-N# 38(M) ≥32 VCT, SC, M (110-120) V~, 60Hz R-600a / 1.76 oz (50 g) 1.4 A
TGM-7SD*-N# 38(M) ≥32 VCT, SC, M (110-120) V~, 60Hz R-600a / 1.94 oz (55 g) 1.4 A
TGM-10SD*-N#
38(M)
≥32
VCT, SC, M
(110-120) V~, 60Hz
R-600a / 2.12 oz (60 g)
1.9 A
TGM-12SD*-N# 38(M) ≥32 VCT, SC, M (110-120) V~, 60Hz R-600a / 2.12 oz (60 g) 1.9 A
TGM-15SD*-N# 38(M) ≥32 VCT, SC, M (110-120) V~, 60Hz R-600a / 2.29 oz (65 g) 2.1 A
TGM-20SD*-N# 38(M) ≥32 VCT, SC, M (110-120) V~, 60Hz R-600a / 3.00 oz (85 g) 2.4 A
TGM-23SD*-N# 38(M) ≥32 VCT, SC, M (110-120) V~, 60Hz R-600a / 2.82 oz (80 g) 2.7 A
TGM-35SD*-N# 38(M) ≥32 VCT, SC, M (110-120) V~, 60Hz R-290 / 3.53 oz (100 g) 3.3 A
TGM-47SD*-N# 38(M) ≥32 VCT, SC, M (110-120) V~, 60Hz R-290 / 3.70 oz (105 g) 3.4 A
TGM-72SD*-N# 38(M) ≥32 VCT, SC, M (110-120) V~, 60Hz R-290 / 4.06 oz (115 g) 7.9 A
VCT : VERTICAL CLOSED TRANSPARENT
VCS : VERTICAL CLOSED SOLID
HCT : HORIZONTAL CLOSED TRANSPARENT
HCS : HORIZONTAL CLOSED SOLID
SC : SELF-CONTAINED
M : MEDIUM TEMPERATURE APPLICATION
L : LOW TEMPERATURE APPLICATION
Freezers
Model
Rating
Temp.
(
℉
)
Operating
Temp.
(
℉
)
Equipment
Class
Designation
V/Hz Refrigerant AMPS
TGF-5SD*-N# 0(L) <32 VCT, SC, L (110-120) V~, 60Hz R-290 / 3.53 oz (100 g) 2.3 A
TGF-10SD*-N# 0(L) <32 VCT, SC, L (110-120) V~, 60Hz R-290 / 3.70 oz (105 g) 2.6 A
TGF-15SD*-N# 0(L) <32 VCT, SC, L (110-120) V~, 60Hz R-290 / 4.23 oz (120 g) 5.6 A
TGF-23SD*-N# 0(L) <32 VCT, SC, L (110-120) V~, 60Hz R-290 / 3.88 oz (110 g) 6.0 A
TGF-35SD*-N# 0(L) <32 VCT, SC, L (110-120) V~, 60Hz R-290 / 4.23 oz (120 g) 8.1 A
TGF-47SD*-N# 0(L) <32 VCT, SC, L (110-120) V~, 60Hz R-290 / 5.11 oz (145 g) 10.4 A
TGF-72SD*-N# 0(L) <32 VCT, SC, L (110-120) V~, 60Hz
R-290 / 5.11 oz (145 g)
EA
15.7 A
The serial number can be found on the data label located inside the unit.
Please retain the unit serial number for service purposes.
SERIAL NUMBER
