Table 1. INDOOR UNIT - Medium Temperature (Air Defrost System)
Model
Ambient 95℉
Voltage MCA MOPD
Refrigerant.
Plug
Supplied
Matching
NEMA
Receptacle
NET
Weight
(Lbs)
Fig.Capacity BTUH
Ref.
Wt
oz
35℉ 38℉
STI068MR448A2 6626 6998 208~230/1/60 9.1 15 R448A 54 YES 6-15R 219 A
STI075MR448A2 7803 8186 208~230/1/60 11.4 15 R448A 54 YES 6-15R 218 A
STI100MR448A2 11690 12428 208~230/1/60 16.8 25 R448A 88 YES 6-20R 300 B
STI100MR448A3 11806 12527 208~230/3/60 9.4 15 R448A 88 NO - 300 B
STI130MR448A2 13242 13981 208~230/1/60 16.1 25 R448A 88 NO - 300 B
STI130MR448A3 13283 14107 208~230/3/60 13.9 20 R448A 88 NO - 300 B
Table 2. INDOOR UNIT – Low Temperature (Electric Defrost System)
Model
Ambient 95℉
Voltage MCA MOPD
Refrigerant.
Plug
Supplied
Matching
NEMA
Receptacle
NET
Weight
(Lbs)
Fig.
Capacity BTUH
Ref.
Wt
oz
0℉ −10℉ −20℉
STI022LR448A2 3451 2773 2193 208~230/1/60 9.6 15 R448A 53 YES 6-15R 216 A
STI045LR448A2 5417 4187 3197 208~230/1/60 16.6 25 R448A 53 YES 6-15R 216 A
STI055LR448A2 7499 5903 4568 208~230/1/60 17.9 30 R448A 85 YES 6-20R 288 B
STI055LR448A3 7540 5939 4559 208~230/3/60 17.2 25 R448A 85 NO - 288 B
STI070LR448A2 8414 6718 5275 208~230/1/60 22.6 35 R448A 85 NO - 288 B
STI070LR448A3 8414 6718 5275 208~230/3/60 20.6 30 R448A 85 NO - 288 B
Table 3. OUTDOOR UNIT - Medium Temperature (Air Defrost System)
Model
Ambient 95℉
Voltage MCA MOPD
Refrigerant.
Plug
Supplied
Matching
NEMA
Receptacle
NET
Weight
(Lbs)
Fig.Capacity BTUH
Ref.
Wt
oz
35℉ 38℉
STX068MR448A2 6626 6998 208~230/1/60 9.1 15 R448A 54 NO - 233 C
STX075MR448A2 7803 8186 208~230/1/60 11.4 15 R448A 54 NO - 231 C
STX100MR448A2 11690 12428 208~230/1/60 16.8 25 R448A 88 NO - 317 D
STX100MR448A3 11806 12527 208~230/3/60 9.4 15 R448A 88 NO - 317 D
STX130MR448A2 13242 13981 208~230/1/60 16.1 25 R448A 88 NO - 317 D
STX130MR448A3 13283 14107 208~230/3/60 13.9 20 R448A 88 NO - 317 D
Table 4. OUTDOOR UNIT – Low Temperature (Electric Defrost System)
Model
Ambient 95℉
Voltage MCA MOPD
Refrigerant.
Plug
Supplied
Matching
NEMA
Receptacle
NET
Weight
(Lbs)
Fig.
Capacity BTUH
Ref.
Wt
oz
0℉ −10℉ −20℉
STX022LR448A2 3451 2773 2193 208~230/1/60 9.6 15 R448A 53 NO - 230 C
STX045LR448A2 5417 4187 3197 208~230/1/60 16.6 25 R448A 53 NO - 230 C
STX055LR448A2 7499 5903 4568 208~230/1/60 17.9 30 R448A 85 NO - 305 D
STX055LR448A3 7540 5939 4559 208~230/3/60 17.2 25 R448A 85 NO - 305 D
STX070LR448A2 8414 6718 5275 208~230/1/60 22.6 35 R448A 85 NO - 305 D
STX070LR448A3 8414 6718 5275 208~230/3/60 20.6 30 R448A 85 NO - 305 D
