21
REVERSIBLE DOOR INSTRUCTIONS
(For M3R19-1-N / M3R24-1-N / M3F19-1-N / M3F24-1-N)
G. Assemble stopper plate in original positions.
H. Assemble the door, then rotate it about 180
degrees. Assemble top hinge (right) with stopper
plate in bottom hinge (left) position (First, assemble
top hinge (left); second, assemble bottom hinge (left)
while doors are closed, insert hinge into door
bushing (left) with lifting, rotate doors counter
-clockwise, screw hinge in original positions).
I. Assemble top hinge (right) with fixtures in original
positions.
J. Screw top grille (T) and top grille (B) (This process
is opposite of disassembling).
E. Disassemble stopper plate which located on
bottom hinge (right), then assemble bottom
hinge (right) on position of top hinge (left).
F. Disassemble stopper plate, then tight screws.
