13
BASIC OPERATION
DISPLAY PANEL OF REFRIGERATOR
REFRIGERATORS
M3R19-1-N
M3R24-1-N
M3R24-2-N
M3R24-2-N-L
M3R47-2-N
M3R47-2-N-AL
M3R47-2-N-AR
M3R47-4-N
M3R72-3-N
M3R72-3-N-AL
M3R72-3-N-AR
M3R72-6-N
M3R24-1-G-N
M3R24-1-G-N-L
M3R47-2-G-N
1. Plug in and turn on the power switch located on the control box. The Display
panel will be lighted and make a beep sound. The compressor will begin to run.
2. The default temperature setting is No. “4”.
3. The compressor is automatically cycled by the electronic controller (PCB, RD-Sensor).
4. The Defrost cycle is automatically controlled by the PCB.
5. Set level toward “1” for higher temperature and toward “7” for lower temperature.
6. The interior light is activated by the switch at the bottom of the grille when
the door is opened.
7. Evaporator fan motor(s) will run after all doors are completely closed.
TEMP. SETTINGTEMP. CONTROL BUTTON
INNER TEMP.
(SEE PAGE 14)
(SEE PAGE 14)
TEMPERATURE
TURBO
COOLING
POWER
TEMPERATURE
