8
ź Unscrew the control knob for adjustment of cutting depth (11), use the
socket wrench (21) to loose the fixing bolt with a hexagonal socket (9)
and pivot the spindle (8) and the cutting depth limiter (10) (Fig. B, page
3).
ź Fix position of the spindle (26) with use of the spindle lock (16) and then
use the alligator wrench (20) to unscrew the fixing nut (22).
WARNING! Do never activate the spindle lock (16) when the tool is running. It
may lead to damage of the tool.
ź Remove the fixing nut (22), spacing washers (25), cutting blades (18)
and two flanges – the fixing one (23) and the inner (rest) one (24) from
the spindle. Clean the spindle of the grooving machine as well as all the
other components prior to having them reassembled (see Fig. C, page 3).
ź Slide the inner (rest) flange (24) with the protruding side with a groove
onto the spindle stem so that to have the flange engaged on the spindle.
Now it is possible to assemble new diamond cutting blades (18) together
with spacing washers (25) in the reverse order to achieve the required
groove width. Make sure that all the parts well fit to each other and are
firmly fixed.
NOTE! During assembling the diamond cutting blades make sure that arrows
that indicate rotation direction on diamond blades match the arrows (17) that
indicate the rotation speed of the tool and are placed on the tool shield and
head.
When the tool is used with two diamond blades, they should also be replaced
in pairs.
n Adjustment of the groove width
The tool is provided with 6 spacing nuts (25) with the width of ca. 3,5 mm.
The groove width depends on the number of spacing washers placed in
between the both diamond cutting blades (18), the width of the fixing
flange (23) and on cutting with of the diamond cutting blades (18).
The groove width shall be calculated in the following way:
Groove width = thickness of spacing washers + thickness of the fixing ring
+ width of the diamond cutting blades.
The range of allowed groove width is specified in the section «Technical
parameters».
Regardless the adjusted groove width all the remaining spacing washers
(25) must be installed in between the blade and the fixing nut. Otherwise
the diamond cutting blade may get loose during the electric tool operation,
which may lead to injuries to operators.
n Preliminary adjustment of the groove depth or cutting depth
NOTE: The preliminary adjustment of the groove depth or cutting depth can be
carried out only when the electric tool is off.
Loose the control knob for adjustment of cutting depth (11) and roughly set
the cutting depth by pivoting the cutting depth limiter (10) against the
scale for adjustment of cutting depth (13).
Then retighten the knob (11).
WARNING: The installed cutting blades (18) protrude outsider the protecting
cover even when the cutting depth is set to the minimum. Therefore the electric
tool must never be left standing on the guide roller (15), lay the tool on its side
instead.
n Connection of a vacuum cleaner (Fig. D, page 3)
NOTE! Dust that is emitted during the tool operation may be hazardous for
health, inflammable or explosive.
It is always mandatory to observe all the laws and regulations that are
effective in the country of the tool application and govern rules for handling
material to be machined.
To evacuate dust from the tool it is necessary to connect a vacuum cleaner
either directly to the port (5) or with use of a appropriate adapter.
It is recommended to use vacuum cleaners designed for industrial
applications.
PRIOR TO COMMENCE WORKING WITH THE TOOL:
1. Make sure that electric parameters of the power voltage correspond to
parameters of the electric tool according to specifications on the rating
plate.
2. Make sure that the On/Off switch (3) of the electric tool is in its Off
position.
3. While working with a power cord extension make sure that electric
parameters of the extension cable and cross-sections of its wires are
appropriated for corresponding parameters of the electric tool. The
extension cable must be fully uncoiled.
OPERATION:
n Switching the tool on and off
To protect operators against accidents the tool is provided with an unlocking
button for the on/off trigger.
ź To switch the tool on it is first necessary to depress the unlocking button
(2) and then depress the On/Off trigger (3) and hold it depressed.
ź To switch the tool off it is enough to release the On/Off trigger (3).
NOTE: Due to safety reasons the On/Off trigger (3) cannot be locked for
continuous operation. It must be kept depressed manually by the operator
during the entire time of the tool operation.
n Motor
During the motor operation it must be well ventilated, it is why the
ventilation slots must be always kept clean and unclogged.
When the motor is overloaded it stops automatically. Immediately release
the loads from the tool and let the motor run for about 60 seconds at the full
rotation speed in order to cool down the motor.
n Operation tips
NOTE! The tool is designed exclusively for dry cutting!
Adjust the preliminary cutting depth as described in the section
«Preliminary adjustment of the groove depth or cutting depth».
TIP: To level possible roughness that are left after removing the excavated
material the cutting depth must by deeper by 3 mm that the required depth of
the recess.
The tool must be operated with holding it with two hands for two handles
(Fig. E, page 3).
1. Attach the tool to the contact of the guiding roller (15) so that the
diamond blades would be still elevated above the machined material.
2. Switch the tool on and slowly immerse the blades into the material.
3. Drive the tool gently with moderate speed corresponding to the
machined material. Be careful to follow the cutting line!
NOTE: The cutting blades must always rotate to the opposite direction to the
tool advance so that attach the machined surface. Operation with any other
direction is not allowed as it may cause uncontrolled jerks of the tool and
breakout of the cutting direction.
At the end of the cutting line, lift the tool to pull up the rotating diamond
blades from the groove and then switch the tool off. Do never brake the
runout of rotating disks depressing their side surfaces to other objects.
WARNING! Diamond disks are getting very hot during cutting, do never touch
them before letting them cool down.
The remaining strip of material that may be left in the groove should be
removed with use of the cleaning wedge (Fig. F, page 3).
Cutting is only possible along straight lines, any attempt to cut down bends
