16
© 2024 TRUE Fitness All Rights Reserved.
Step 2—Attach the Inner Guard Shroud to the Frame
T
O
W
AR
D
S
T
A
I
R
S
I
n
st
a
l
l
w
i
t
h
c
ab
l
e
t
i
e
o
n
u
s
er
l
e
f
t
s
i
d
e
.
ti
e
.
R
ou
t
e
ca
b
l
e
th
r
o
u
g
h
c
a
b
l
e
2
1
4
3
Parts Used in this Step
Item Part Description Qty
1 VC90003-35 WELDMENT, UPPER FRAME 1
2 VC90250-35 VC900 BASE ASSEMBLY 1
3 VC90103 SHROUD, INNER GUARD 1
4 VC90148 PHMS, M5-0.8 X 12MM, ZP 4
Tools Used in this Step
#2 Phillips Screwdriver
A. Be sure the cable bundle is pulled out of the base and
carefully draped over the left side of the base.
B. Attach the inner guard shroud to the base using four
screws.
NOTE: It helps to partially thread each side screw
and then slide the inner guard shroud over the two
side screws to help hold it in place as you continue to
install and tighten all screws.
