TEC_TM_009 REV. L_EN
01/02/2025
Page 43 of 76
TR-24/30/36 INSTALL MANUAL
PAGE TITLEAPPLIANCE SETUP
FIG. 6.
Push the bottom tab inward.
FIG . 7.
Completed shelf installation.
FIG. 3.
Remove the shelf shipping clip (A) from the shelf standard (B).
1
2
A B
FIG. 5.
Underside view. Left side shown.
A: CORRECT;
Bottom tab is fully seated in the shelf standard.
B: INCORRECT;
Bottom tab is not seated in the shelf standard.
A B
FIG. 4.
Lift the shelf front up (A). Then, lift the shelf back and pull
forward (B).
A B
1
2
SHELF ADJUSTMENT (CONT.)
PROCEDURE
1. Remove the shelf shipping clips. See fig. 3.
2. Remove the shipping tape from the shelf.
NOTE: TRUE RECOMMENDS PULLING THE
TAPE FROM THE TOP.
3. Remove the shelf. See fig. 4.
4. Install the shelf at the desired height.
NOTE: BE SURE THE SHELF IS FULLY
SEATED. SEE FIG. 5. PUSH THE BOTTOM
TABS INWARD IF THE SHELF DOES NOT SIT
FLAT. SEE FIG. 6.
5. Repeat steps 2-4 for the remaining shelves.
6. Remove the side microfilm. See fig. 7.
