TEC_TM_009 REV. L_EN
01/02/2025
Page 32 of 76
TRUE RESIDENTIAL
®
#212530
PAGE TITLEINSTALLATION
KIT CONTENTS
• (1) One anti-tip bracket (fig. 1)
• (4) Four 3⁄16" masonry screws
• (8) Eight #12-2" wood screws
• (12) Twelve 1/4" washers
REQUIRED TOOLS
Required tools include (but may not be limited to) the
following:
• Tape measure
• Marking utensil
• 1/8" drill bit
• 7/16" socket
• Phillips bit driver
• Drill or ratchet
PROCEDURE
1. Measure and mark the anti-tip bracket’s placement
in the installation location. See fig. 2.
2. Position the bracket. Then, with the bracket as a
guide, drill pilot holes into the wall and/or floor.
NOTE: FOR INCREASED STABILITY, SECURE THE
BRACKET TO AS MANY JOISTS AND/OR STUDS
AS POSSIBLE.
3. With the provided hardware, secure the anti-tip
bracket.
4. Adjust the rear leveling rollers 1/4 turn clockwise.
5. Slide the unit into place and hook the anti-tip
bracket into the castor assembly slots.
ANTI-TIP BRACKET INSTALLATION (REQUIRED)
FIG. 1.
Anti-tip bracket. Do not discard.
WARNING! TIP OVER HAZARD. Unit
poses a tipping hazard when moving or
during installation. Do not move the unit
without the shipping brackets installed.
Do not remove the appliance from the
pallet without assistance. Failure to
do so may result in property damage,
personal injury, or death.
WARNING! TIP OVER HAZARD. Anti-
tip bracket must be installed to ensure
personal safety, correct operation, and
proper airflow.
USER ACTION!
• Install the anti-tip bracket before
moving the unit into its final
operating position.
• Contact a qualified flooring installer
for the best procedure of drilling
pilot holes through your flooring
material.
