TEC_TM_087 REV. A 09/25/2020 Page 13 of 18
truemfg.com
THAC | HORIZONTAL AIR CURTAIN
CAUTION - Take care during operation, maintenance or repairs
to avoid cuts or pinching from any cabinet part/component.
Cleaning the Condenser Coil
When using electrical appliances, basic safety precautions should
be followed, including the following:
WARNING – DO NOT clean appliance with a pressure
washer or hose.
CAUTION – Fins are sharp. Caution must be used to
avoid eye injury. Eye protection is recommended.
Tools Required
• Phillips screwdriver
• 1/4" nut driver
• 3/8" nut driver
• Stiff bristle brush
• Tank of compressed air
• Vacuum cleaner
• Flashlight
• Eye protection
1. Disconnect power to unit.
2. Remove the screw securing the louvered grill to the cabinet.
See fig. 1.
3. Pull on the grill assembly to release it from the magnetic
brackets. See fig. 2.
4. Carefully clean off accumulated dirt from the front fins of the
condensing coil with a stiff bristle brush. See fig. 3.
5. With dirt removed from the surface of the coil, use a flashlight
to verify that you can see through the coil and observe the
condenser fan blade spinning. See fig. 4.
If the view is clear, reinstall louvered grill, connect unit to
power and verify operation.
If the view is still blocked with dirt, proceed to step 6.
Maintenance, Care & Cleaning
Fig. 1. Louver grill screw locations.
Fig. 2. Carefully remove the grill.
Fig. 3. Never brush across the coil fins.
Fig. 4. Verify all blockages have been removed.
