THAC | HORIZONTAL AIR CURTAIN truemfg.com
TEC_TM_087 REV. A09/25/2020 Page 10 of 18
Cabinet Setup
Shelving Installation
NOTE: For ease of installation, it is recommended that the
lower shelf be installed first.
1. Install the shelf risers as shown in figs. 1a-c.
2. Slide the shelf supports into the front most riser slots.
See fig. 1c.
3. Firmly press the shelves over the risers. See fig. 2.
NOTE: Be sure each shelf is fully seated.
Fig. 1a. Position the shelf risers at the indicated areas.
Fig. 2. Position the shelves as shown.
Fig. 1b. Carefully slide the risers onto the back wall.
Fig. 1c. Installed shelf risers and shelf supports.
CAUTION – DO NOT load product past the load limit line!
