REFRIGERATED FOOD PREP truemfg.com
TEC_TM_090 | REV. F | EN
P#975530
01/14/2025 Page 38 of 44
Maintenance & Servicing (cont.)
False bottom Panel Removal/Installation (TSSU)
False bottom panes, located underneath the product pans, are
removable for cleaning and sanitizing. These panels must be
installed for correct appliance operation and product temperatures.
NOTICE ›
The quantity of panels varies by model. Not all
components shown in the following images are used in all
applications.
Removal
Non-Mega Single Door Units
With product removed, tilt the panel and pull it forward.
Non-Mega Two & Three-Door Units
1. Remove or loosen the false bottom baffle.
2. With the top product removed, tilt and lift the panels from
the top.
False bottom baffle
Mega Units
With the top product pans removed, tilt and lift the panel from
the top.
False Bottom Panels
Installation
NOTICE ›
When reinstalling the false bottom panels, be sure
the vertical bend is positioned at the front of the appliance
and
facing up.
Non-Mega Single Door Units.
Perform the reverse procedure of removal.
Mega & Non-Mega Two & Three-Door Units
1. Position the bottom support with the rear tabs seated in the
correct slots in the top of the shelf bracket.
2. If so equipped, be sure to reinstall the false bottom baffle.
3. Position the panels.
