REFRIGERATED FOOD PREP truemfg.com
TEC_TM_090 | REV. F | EN
P#975530
01/14/2025 Page 24 of 44
Appliance Operation (cont.)
General Sequence of Operation — Refrigerators & Freezers
USER ACTION!
For more information regarding an appliance's temperature control adjustment or general sequence of operation,
please see our Commercial Refrigeration General Control Guide in our resource library at
truemfg.com/support/manuals/#panel4 or scan the QR code.
When the appliance is plugged in…
1. The interior lights illuminate on glass door models (if not, see “Light Switch Location” (pg. 21).
2. The electronic temperature control display illuminates (if installed).
When the appliance is in refrigeration mode
1. There may be a short delay before the compressor and/or evaporator fan(s) start. This delay may be determined by time
or by temperature. This delay may also be the result of an initial defrost event that will be a minimum of six (6) min.
2. The temperature control/thermostat may cycle the compressor and evaporator fan(s) on and off together.
EXCEPTION: models TSID, TDBD, TCGG, and TMW do not have evaporator fan(s).
3.
The temperature control cycles the compressor by sensing either an evaporator coil temperature or air temperature, not a
product temperature.
a. Mechanical Temperature Control or Electronic Temperature Control with a Knob
i. The temperature control cycles the compressor on and off as determined by the cut-in and cut-out temperatures.
1. #9 is the coldest position
2. #1 is the warmest position
3. #0 or Off is the compressor off position
b. Electronic Temperature Control with a Display
i. The temperature control cycles the compressor on and off as determined by the set point and differential temperatures.
1. The set point is the adjustable preprogrammed temperature designed to be either the cut-out temperature or it will
match the average appliance holding temperature (only when used with a high and low differential).
2. The differential temperature(s) is the non-adjustable preprogrammed temperature used to determine when the
compressor turns on and off (only when the set point is the average holding temperature).
4. An analog thermometer, a digital thermometer, or an electronic control display may reflect the refrigeration cycle swings of up
and down temperatures, not a product temperature. The most accurate method to determine an appliance’s operation
is to verify the product temperature.
5. There may be times during refrigeration mode or defrost mode that the condenser fan motor will reverse to blow dirt off the
condenser coil.
