TEC_TM_180 | REV. E | EN 03/12/2024 Page 15 of 44
RETAIL MERCHANDISER truemfg.com
Installation & Setup (cont.)
1. Remove the shelf shipping bracket, shelf cable ties, and
shipping tape. See figs. 2 and 3.
2. Lift the shelf assembly and then pull the shelf assembly
forward. See fig. 4.
3. Hook the shelf assembly into the shelf standards at the desired
height.
4. Repeat steps 1-3 for the remaining shelves.
Fig. 1. Plugging (A) and capping (B) a leveling leg hole.
Fig. 3. Shelf cable ties and shipping tape. Not all cable ties or tape shown.
Shelf Adjustment
Fig. 2. Shelf shipping bracket location. One bracket shown.
Fig. 4. Lift the shelf and pull forward.
A
A
B
B
USER ACTION!
DO NOT adjust shelving until AFTER the installation
process is complete. Foam cylinders and caps MUST
be installed in the leveling leg holes. See fig 1. Please
see installation packet for more details
