12
TRUE
SPEC SERIES: STR, STA & STG HEATED CABINETS
WWW.TRUEMFG.COM
STARTUP
A. The cabinet is ready to operate. Plug in the unit.
B. Temperature controls are factory-set to maintain an approxiate
temperature of 140°F -180°F (60°C-82°C). Allow unit to
function several hours, completely heating cabinet before
changing the control setting.
Temperature Control Location and Settings.
• LAE temperature control is located on the front of cabinet
in louvered grill.
• Mechanical temperature control is located on the front of
cabinet in louvered grill.
See website for adjustments, sequence of operation, and more
information.
C. Excessive tampering with the control could lead to service
difficulties. Should it ever become necessary to replace
temperature control, be sure it is ordered from your TRUE
dealer or recommended service agent.
D. Good air flow in your TRUE unit is critical. Be careful to
load product so that it neither presses against the back wall,
nor comes within four inches of the evaporator housing.
Refrigerated air off the coil must circulate down the back wall.
NOTE: If the unit is disconnected or shut off, wait five minutes
before starting again.
RECOMMENDATION - Before loading product we recommend
you run your TRUE unit empty for two to three days. This allows
you to be sure electrical wiring and installation are correct and no
shipping damage has occurred. Remember, our factory warranty does
not cover product loss!
OPERATION
MECHANICAL TEMPERATURE CONTROLS
AIR SENSING
MECHANICAL TEMPERATURE CONTROL GENERAL SEQUENCE OF OPERATION
MECHANICAL CONTROL HEATED CABINET GENERAL SEQUENCE OF OPERATION
1. Cabinet is plugged in.
a. Interior lights will illuminate if the rocker switch on the outside panel is in the “ON” position.
2. The temperature control will energize the heat elements if the control is calling for heat.
3. The temperature control will cycle the heating elements on and off.
a. The temperature control is sensing the air temperature.
b. The temperature control should be set between 140°F-180°F (60ºC-82ºC).
c. The temperature control has an “OFF” position.
d. The thermometer is designed to read and display a cabinet temperature not a product temperature. This cabinet
temperature may reflect the heating cycle determined by the temperature control. The most accurate temperature on a
cabinets operation is to verify the product temperature.
