Je bekijkt pagina 17 van 20
BN 2645198 2645199 2645200 2645201
Customer # DPN-24120 DPS-24120 DPH-12015 DPH-24015
Product name
Din Rail Power Supply 24 V/DC 5A
120W
Din Rail Power Supply 24 V/DC 5A
120W
Din Rail Power Supply 12 V/DC 1.25A
15W
Din Rail Power Supply 24V/DC 0.625A
15W
Rated input 100-240 V/AC, 50/60 Hz 100-240 V/AC, 50/60 Hz 100-240 V/AC, 50/60 Hz 100-240 V/AC, 50/60 Hz
Input voltage range
90-264 V/AC or 127-370 V/DC
[DC input by connecting AC/L(+),
AC/N(-)]
90-264 V/AC or 127-370 V/DC 90-264 V/AC or 127-370 V/DC 90-264 V/AC or 127-370 V/DC
Frequency range 47-63 Hz 47-63 Hz 47-63 Hz 47-63 Hz
Efciency (Typ.) 88 % 91 % 85% 86%
AC current (Typ.)
2.25 A/115 V/AC
1.3 A/230 V/AC
1.4 A/115 V/AC
0.7 A/230 V/AC
0.5 A/115 V/AC
0.25 A/230 V/AC
0.5 A/115 V/AC
0.25 A/230 V/AC
Inrush current (Typ.)
20 A/115 V/AC
35 A/230V/AC
35 A/115 V/AC
70 A/230 V/AC
25 A/115 V/AC
45 A/230 V/AC
25 A/115 V/AC
45 A/230 V/AC
Leakage current <1 mA/240 V/AC <1 mA/240 V/AC 0.707 mA/264 V/AC 0.707 mA/264 V/AC
Power Factor Correction (PFC) NA Built-in, active NA NA
Ripple & Noise (max.) 120 mVp-p 100 mVp-p 120 mVp-p 150 mVp-p
Voltage tolerance ±2.0 % ±2.0 % ±2.0 % ±2.0 %
Line regulation ±0.5 % ±0.5 % ±1.0 % ±1.0 %
Load regulation ±1.0 % ±1.0 % ±1.0 % ±1.0 %
Setup, rise time
1200 ms, 60 ms/230 V/AC at full load
2500 ms, 60 ms/115 V/AC at full load
1500 ms, 60 ms/230 V/AC at full load
3000 ms, 60 ms/115 V/AC at full load
2000 ms, 80 ms/230 V/AC at full load
2000 ms, 80 ms/115 V/AC at full load
2000 ms, 80 ms/230 V/AC at full load
2000 ms, 80 ms/115 V/AC at full load
Hold up time (Typ.)
16 ms/230 V/AC at full load
10 ms/115 V/AC at full load
20 ms/230 V/AC at full load
15 ms/115 V/AC at full load
30ms/230 V/AC at full load
12 ms/115 V/AC at full load
30 ms/230 V/AC at full load
12 ms/115 V/AC at full load
Voltage adjustment range 24 - 28 V/DC 24 - 28 V/DC 10.8 -13.8 V/DC 21.6 - 29 V/DC
Output voltage (min.) 24 V/DC 24 V/DC 12 V/DC 24 V/DC
Output voltage (max) 28 V/DC 28 V/DC 13.8 V/DC 29 V/DC
Output current (max) 5 A 5 A 1.25 A 0.625 A
Rated Power 120 W 120 W 15 W 15 W
Output power characteristic N/A High peak power 150 W (3 secs) N/A N/A
DC power good signal N/A Built-in DC okay relay contact N/A N/A
Withstand voltage
I/P-O/P: 3 kV/AC
I/P-FG: 2 kV/AC
O/P- FG: 0.5 kV/AC
I/P-O/P: 3 kV/AC
I/P-FG: 2 kV/AC
O/P- FG: 0.5 kV/AC
I/P-O/P: 3 kV/AC
I/P-FG: 2 kV/AC
O/P- FG: 0.5 kV/AC
I/P-O/P: 3 kV/AC
I/P-FG: 2 kV/AC
O/P- FG: 0.5 kV/AC
Isolation resistance
I/P-O/P, I/P-FG, O/P-FG: > 100M
Ohms / 500V/DC / 25 °C / 70% RH
I/P-O/P, I/P-FG, O/P-FG: > 100M
Ohms / 500V/DC / 25 °C / 70% RH
I/P-O/P: > 100M Ohms / 500V/DC /
25 °C / 70% RH
I/P-O/P: > 100M Ohms / 500V/DC /
25 °C / 70% RH
DIN rail compatability
TS-35/7.5 or TS-35/15
EN/IEC 60715 (DIN rail)
TS-35/7.5 or TS-35/15
EN/IEC 60715 (DIN rail)
TS-35/7.5 or TS-35/15
EN/IEC 60715 (DIN rail)
TS-35/7.5 or TS-35/15
EN/IEC 60715 (DIN rail)
Output connection type Screw DIN terminal Screw DIN terminal Screw DIN terminal Screw DIN terminal
Input / output connector pin
count
Input: 3 poles
Ouput: 4 poles
Input: 3 poles
Ouput: 4 poles
Input: 2 poles
Ouput: 2 poles
Input: 2 poles
Ouput: 2 poles
Outputs 1 1 1 1
Operating orientation Vertical (input terminals down) Vertical (input terminals down) Vertical (input terminals down) Vertical (input terminals down)
Protection mechanisms
Short circuit, over load, over voltage,
over temperature
Short circuit, over load, over voltage,
over temperature
Short circuit, overload, over voltage Short circuit, overload, over voltage
Overload protection behaviour
Trip Point: hiccup mode
Recovery: Automatic after fault
condition is removed
Trip Point: Output shutdown on
overload,Automatic after fault
condition is removed
Trip Point: hiccup mode
Recovery: Automatic after fault
condition is removed
Trip Point: hiccup mode
Recovery: Automatic after fault
condition is removed
Overvoltage protection
Trip point: 29-33 V
Action: Output shutdown
Recovery: After discharge, restart the
power supply to recover
Trip point: 29-33 V
Action: Output shutdown
Recovery: After discharge, restart the
power supply to recover
Trip point: 14.2-16.2 V
Action: Output shutdown
Recovery: After discharge, restart the
power supply to recover
Trip point: 30-36 V
Action: Output shutdown
Recovery: After discharge, restart the
power supply to recover
Over temperature protection
Action: Output shutdown
Recovery: Re-power the unit after
sufcient cooling
Action: Output shutdown
Recovery: Re-power the unit after
sufcient cooling
N/A N/A
Over voltage category N/A N/A II II
Cooling method Convection Convection Convection Convection
Fuse T5A/L250 T3.15A/L250V T2A/L250V T2A/L250V
Max. connected products per
circuit breaker
Type C16: 13 pcs
Type D16: 26 pcs
Type C16: 24 pcs
Type D16: 48 pcs
Type C16: 98 pcs
Type D16: 196 pcs
Type C16: 98 pcs
Type D16: 196 pcs
Terminal screw torque
Inputs: 0.5 N·m
Outputs: 0.5 N·m
Inputs: 0.5 N·m
Outputs: 0.5 N·m
Inputs: 0.4 N·m
Outputs: 0.4 N·m
Inputs: 0.4 N·m
Outputs: 0.4 N·m
Ingress protection N/A N/A IP20 IP20
Operating conditions -20 to +70 °C -25 to +70 °C -20 to +70 °C -20 to +70 °C
Operating humidity 20-95 % RH (non-condensing) 20-95 % RH (non-condensing) 20-90 % RH (non-condensing) 20-90 % RH (non-condensing)
Storage conditions -40 to +85 °C -40 to +85 °C -40 to +85 °C -40 to +85 °C
Storage humidity 10-95 % RH (non-condensing) 10-95 % RH (non-condensing) 10-95 % RH (non-condensing) 10-95 % RH (non-condensing)
Temperature derating De-rating from 50 - 70 °C De-rating from 50 - 70 °C De-rating from 50 - 70 °C De-rating from 50 - 70 °C
