5
SAFE OPERATION PRACTICES
11. After striking a foreign object, stop the tractor, push the
Start/Stop button, and remove the key. Thoroughly inspect
the tractor for any damage. Repair the damage before
operating.
12. To reduce fire hazard, keep the motor(s) free of grass, leaves
and debris build-up. Follow the post operation tractor care
instructions in the Service and Maintenance section.
13. Check brake operation frequently as it is subjected to wear
during normal operation. Adjust and service as required.
14. Never attempt to make adjustments or repairs to the tractor
without removing the key.
15. Maintain or replace safety and instruction labels, as
necessary.
GENERAL ELECTRIC SAFETY
1. Do not expose the tractor to rain or wet conditions.
2. Do not service the tractor or handle electrical components
with wet hands.
3. Do not operate the tractor in the rain, in wet conditions or on
wet surfaces.
4. To reduce the risk of electric shock, avoid body contact with
grounded conductors, such as metal pipes or wire fences.
5. Do not operate the tractor in explosive atmospheres, such as
in the presence of flammable liquids, gases or dust.
6. For protection against risk of injury or electric shock, do
not replace blown fuses. Your tractor should be serviced
professionally by an authorized dealer.
7. Never douse or hose the tractor with water. Avoid getting
any liquid in the motors and electrical connections. Clean the
tractor after each use. Refer to Service and Maintenance. Do
not use solvents or strong detergents.
BATTERY CHARGER SAFETY
WARNING
Only use an OEM battery charger (T56XXX series ) to
charge the batteries in this tractor. DO NOT attempt to
charge any other batteries with the battery charger
specific to this tractor. Other types of batteries may
burst, causing fire, personal injury or property damage.
1. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery may create a risk of fire when used with another
battery.
2. Do not use the charger in the rain, wet locations or in the
presence of flammable liquids or gasses.
3. A nameplate on the charger indicates the voltage used. Never
connect the charger to an AC voltage that differs from this
voltage.
4. An extension cord should not be used unless absolutely
necessary. Use of an improper extension cord could result in a
risk of fire, electric shock or electrocution.
5. Do not use multiple extension cords.
6. Make sure the extension cord is heavy enough to carry the
current drawn by the charger. An undersized extension cord
will cause a drop in line voltage, resulting in a loss of power
and overheating. If in doubt, use the next heavier gauge cord.
The smaller the gauge number, the heavier the cord.
MINIMUM WIRE SIZE FOR EXTENSION CORDS FOR 120
VOLT APPLIANCES USING 0-6 AMPS
Cord Length (ft.) 25 50 100 150
Wire Size (AWG) 16 16 16 14
7. Make sure the cords are in good condition. Inspect the
battery charger power cord and extension cord periodically.
Look closely for deterioration, cuts or cracks in the insulation.
If either cord is damaged in any manner while plugged in,
disconnect the cord from both the outlet and the charger. Do
not use a damaged cord. Damaged cords should be repaired
or replaced.
8. Do not abuse cords. Never pull or carry the charger by a cord.
Keep cords away from heat, oil, water, sharp edges, and
moving objects. Always grasp the plug when disconnecting
a cord.
9. Never modify a plug, cord or outlet in any way.
10. Ground Fault Circuit Interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) to be used with
this charger. For an extra measure of safety, use receptacle
(outlet) with built-in GFCI protection.
11. Do not place the battery charger where cords might be
stepped on, tripped over or subjected to damage.
12. Keep the battery charger and cords in a cool and dry area.
13. Keep the battery charger and cords away from all liquids.
14. Do not allow small metal items or material such as steel wool,
aluminum foil or other foreign particles into the charger port.
15. Do not probe the charger with conductive material. There is a
risk of electric shock.
16. Do not cover the battery charger. The battery charger may
overheat.
17. Do not allow the battery or battery charger to overheat.
If they are warm, allow them to cool down. Only charge
batteries in temperatures between 32° and 104° F (0° and
40° C).
