EN 7
local air conditioner PAC-C 1500 S
Transport and storage
Notice
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
Please note that additional transport regulations might apply to
devices containing flammable refrigerants. The equipment's
arrangement and the maximum number of components to be
transported together can be gathered from the applicable
transport regulations.
To make the device easier to transport, it is fitted with a carry
handle.
Before transporting the device, observe the following:
• Switch off the device by pressing the Powerbutton(29).
• Disconnect the device from the mains by removing the
mains plug from the socket. When doing so, be sure to
hold the plug, not the cable.
• Drain the remaining condensate from the device.
• Do not use the power cable to drag the device.
After transporting the device, proceed as follows:
• Set up the device in an upright position after transport.
• Mount the device as described in the Assembly chapter.
• Leave the device to rest for at least12hours if it has been
tilted by more than 45° during maintenance. During this
time, the lubricating oil can be returned to the compressor.
Wait 12hours before switching the device back on! Acting
contrary might lead to compressor damage and a
malfunctioning device.
Storage
Before storing the device, observe the following:
• Drain the remaining condensate from the device.
• Disconnect the device from the mains by removing the
mains plug from the socket. When doing so, be sure to
hold the plug, not the cable.
• Take the internal and external unit out of the window and
disassemble both units. In doing this, do not disconnect
the connection line.
When the device is not being used, observe the following
storage conditions:
• Only position the device in rooms where there is no source
of ignition (e.g. open flames, an active gas appliance or an
electric heater).
• Only store the device in a room measuring more than 4m
2
.
• Store the device in a dry location and protected from frost
and heat.
• Store the device in an upright position where it is protected
from dust and direct sunlight.
• If required, use a cover to protect the device from invasive
dust.
• Place no further devices or objects on top of the device to
prevent it from being damaged.
Assembly and start-up
Scope of delivery
• 1x External unit
• 1x Internal unit
• 2x Fixture (inside)
• 2x Fixture (outside)
• 2x Star knob screw
• 12x Screw
• 2x Spacer
• 1x Condensation drain hose
• 1x Protective cover
• 1x Manual
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.
