EN 17
local air conditioner PAC-C 1500 S
Technical annex
Technical data
Parameter Value
Model PAC-C 1500 S
Nominal cooling capacity 1465W
Energy efficiency class A
Energy efficiency ratio EER 2.6
Application area (room
volume), approx.
12 m³
Setting range of the internal
unit
+16°C to +30°C/
35%RH to 80%RH
Operating range of the external
unit
+21°C to +43°C/
35%RH to 80%RH
Refrigerant R290
Refrigerant capacity 130g
Length of the connection line 1 m
GWP factor 0.02
CO
2
equivalent 0.0000026t
Suction side pressure 0.8MPa
Pressure outlet side 2.8MPa
Max. permissible pressure 3.8MPa
Air volume flow per stage,
internal unit
140m³/h(stage1)
200m³/h (stage2)
Sound pressure level, internal
unit
56 dB(A)
Sound pressure level, external
unit
58 dB(A)
Max. sound power, internal
unit
63 dB(A)
Power supply 220~240V 50/60Hz
Protection type internal unit/
external unit
IPX0 / IPX4
Nominal electrical power
consumption
560W
Nominal electrical current
consumption
2.5A
Starting current, LRA 9.8A
Fusing
16A (slow-blowing)
Condensate pump, conveying
capacity
0.5l/h
Dimensions of the internal unit
(lengthx widthx height) 440 x 180 x 315mm
Dimensions of the external unit
(lengthx widthx height) 440 x 215 x 355mm
Parameter Value
Minimum distance to walls and
other objects:
top (A):
rear (B):
sides (C):
front (D):
20 cm
0 cm
20 cm
20 cm
Weight of the internal unit 15kg
Weight of the external unit 2kg
Weight of internal and external
unit incl. connection line
17.5kg
