Low Voltage Pro
List of Functions by Model
CABLE
TEST
Includes TIA586 cable diagram, Pass/Fail, timing (delay, skew)
and impedance (ohms).
CABLE TESTING PACK
MODEL 20 APPS
ID
Locate multiple wall jacks for CAT5/6
and coax. Requires Remote kit(s)
Place a tone on one end and detect it on the far end.
Requires optional Remote Tone Probe.
TONE CABLE DETECTION
S
L
SBL
CTR
SUB
FRFL
SBR
SR
Locate speakers by audibly “popping” them. Alligator
clips included with all LVPro Models.
Especially designed to properly map and label A/V
speaker wires. Requires remote kit.
SPKR 7.1 ID# MAPPER
SPEAKER POPPER
Locate a cable connection to a switch port by blinking the
switch’s Link LED.
PORT BLINK CABLE DETECTION
Detect PoE voltage and display its amplitude and location
on the cable (midspan, endspan or both).
POWER OVER ETHERNET / PAIRS USED
Plug into any active port (computer, switch, VoIP,
access point) and display its capabilities.
10/100/1000 DETECTION/DISPLAY
CCTV systems require a minimum of 1Vpp to DVR.
Measure and display Vpp of video signal.
CCTV / Vpp (peak to peak voltage)
Test alarm system and other backup batteries
by doing a loaded battery test.
ALARM BATTERY TEST (LOADED)
Store for later printing up to 250 tests (all cable types). All
data is stored except RLQ. USB and software included.
STORE AND PRINT UP TO 250 REPORTS
APPS ADDED WITH MODEL 30 & 30SR
- LVPRO Main Unit
- Detachable Remote
- F Male to BNC Male
- F Male to BNC Female
- RJ45 patch cable(2)
- RJ45 to alligator clip adapter
- USB cable, case
- Batteries (4 - AA)
- 10 RJ45 remotes (M30 & 30SR only)
- 10 Coax remotes (M30 & 30SR only)
- RLQ adapters(3) (M30 & 30SR only)
- Smart Remotes (M30SR only)
- User Manual
3
1
2
R
Get perfect length. Use built-in values or calibrate with your
cable. Adds length readout to Cable Test App (cable length,
distance to open or short). Also includes RLQ (below).
Included with the Length-RLQ APP, Return Loss Qual-
ity tests for load mismatches that affect the wire’s power
and data transfer capability. "Green" colored adapters (3
pcs) used with the RLQ test are included.
LENGTH-
RLQ PACK
ITEMS INCLUDED
