8. SPARE & REPLACEMENT PARTS LISTING

G SERIES

Page 16

ITEM/DESCRIPTION

G100/G110

1SECREF

G120XX

1SECFZR

G200/G210

2SECREF

G220XX

2SECFZR

G300/G320

3SECREF

G313XX/G310XX

3SECFZR

DOORS

FullHeightGlassDoor 200-60954-01 callfactory allmodels notavailable allmodels notavailable

HalfHightGlassDoor 200-60953-00 callfactory allmodels notavailable allmodels notavailable

HalfHeightGlassDoor 200-60953-01 callfactory allmodels notavailable allmodels notavailable

GASKETS

FullHeightDoor SVC-60256-00 allmodels allmodels allmodels allmodels allmodels

HalfHeightDoor SVC-60257-00 allmodels allmodels allmodels allmodels allmodels

LOCK

Lockkeeper 358-60707-00 allmodels allmodels allmodels allmodels allmodels

LockCylinder 358-13186-42 allmodels allmodels allmodels allmodels allmodels

LockCylinderAssywithKey SER-13186-42 allmodels allmodels allmodels allmodels allmodels

SHELVES/TRAYSLIDES

EpoxyCoatedShelf(withPins&Clips) G1ACC-SHLF5 G1ACC-SHLF5

LFTSEC:G23ACC-SHLF9

RHTSEC:G23ACC-SHLF11

LFTSEC:G23ACC-SHLF9

RHTSEC:G23ACC-SHLF11

LFTSEC:G23ACC-SHLF9

CENSEC:G3ACC-SHLF15

RHTSEC:G23ACC-SHLF11

LFTSEC:G23ACC-SHLF9

CENSEC:G3ACC-SHLF15

RHTSEC:G23ACC-SHLF11

ShelfPin 358-24759-02 allmodels allmodels allmodels allmodels allmodels

3EpoxyCoatedShelves(withPins) G1ACC-SHLF3 G1ACC-SHLF3

LFTSEC:G23ACC-SHLF1

RHTSEC:G23ACC-SHLF5

LFTSEC:G23ACC-SHLF1

RHTSEC:G23ACC-SHLF5

LFTSEC:G23ACC-SHLF1

CENSEC:G3ACC-SHLF5

RHTSEC:G23ACC-SHLF5

LFTSEC:G23ACC-SHLF1

CENSEC:G3ACC-SHLF5

RHTSEC:G23ACC-SHLF5

3EpoxyCoatedShelves(withPilasters&Clips) G1ACC-SHLF2 G1ACC-SHLF2

LFTSEC:G23ACC-SHLF2

RHTSEC:G23ACC-SHLF6

LFTSEC:G23ACC-SHLF2

RHTSEC:G23ACC-SHLF6

LFTSEC:G23ACC-SHLF2

CENSEC:G3ACC-SHLF6

RHTSEC:G23ACC-SHLF6

LFTSEC:G23ACC-SHLF2

CENSEC:G3ACC-SHLF6

RHTSEC:G23ACC-SHLF6

3PlatedShelves(WithPins) G1ACC-SHLF3 G1ACC-SHLF3

LFTSEC:G23ACC-SHLF3

RHTSEC:G23ACC-SHLF7

LFTSEC:G23ACC-SHLF3

RHTSEC:G23ACC-SHLF7

LFTSEC:G23ACC-SHLF3

CENSEC:G3ACC-SHLF7

RHTSEC:G23ACC-SHLF7

LFTSEC:G23ACC-SHLF3

CENSEC:G3ACC-SHLF7

RHTSEC:G23ACC-SHLF7

3PlatedShleves(withPilasters&Clips) G1ACC-SHLF4 G1ACC-SHLF4

LFTSEC:G23ACC-SHLF4

RHTSEC:G23ACC-SHLF8

LFTSEC:G23ACC-SHLF4

RHTSEC:G23ACC-SHLF8

LFTSEC:G23ACC-SHLF4

CENSEC:G3ACC-SHLF8

RHTSEC:G23ACC-SHLF8

LFTSEC:G23ACC-SHLF4

CENSEC:G3ACC-SHLF8

RHTSEC:G23ACC-SHLF8

#1TraySlides-8Pairs(withPilasters) G1ACC-TK1 G1ACC-TK1 LFT/RHTSEC:G23ACC-TK1LR LFT/RHTSEC:G23ACC-TK1LR

LFT/RHTSEC:G23ACC-TK1LR

CENSEC:G3ACC-TK1C

LFT/RHTSEC:G23ACC-TK1LR

CENSEC:G3ACC-TK1C

#4TraySlides-2Pair(withPilasters) G1ACC-TK2 G1ACC-TK2 LFT/RHTSEC:G23ACC-TK2LR LFT/RHTSEC:G23ACC-TK2LR

LFT/RHTSEC:G23ACC-TK2LR

CENSEC:G3ACC-TK2C

LFT/RHTSEC:G23ACC-TK2LR

CENSEC:G3ACC-TK2C

UniversalTraySlides-7Pairs(withPilasters) G1ACC-TK4 G1ACC-TK4 LFT/RHTSEC:G23ACC-TK4LR LFT/RHTSEC:G23ACC-TK4LR

LFT/RHTSEC:G23ACC-TK4LR

CENSEC:G3ACC-TK4C

LFT/RHTSEC:G23ACC-TK4LR

CENSEC:G3ACC-TK4C

LEGS/CASTERS

Legs6"high(setof4) LK1 allmodels allmodels allmodels allmodels allmodels

LOUVERASSY SK-500-60827-00 SK-500-60827-00 SK-500-60827-02 SK-500-60827-02 SK-500-60827-03 SK-500-60827-03

SENSORS

CabinetSensor 334-60083-01 334-60083-01 334-60083-02 334-60083-02 334-60083-03

G313:334-60083-03

G310:334-60405-02

CoilSensor 334-60084-01 334-60084-01 334-60084-02 334-60084-02 334-60084-03

G313:334-60084-03

G310:334-60406-02

LIGHT

LightBuld-LED 358-60691-00 allmodels allmodels allmodels allmodels allmodels

EVAPORATOR

ExpansionValve 325-60080-37 325-60080-25 325-60080-37 325-60080-26 325-60080-38 325-60080-34

EvaporatorMotorAssy(SheetmetalBoxandFanAssy) SK-600-61081-00 SK-600-61081-00 SK-600-61081-00 SK-600-61081-01 SK-600-61081-01 SK-600-61081-01

EvaporatorMotorAssy(MotorAndBladeAssy) 338-60061-00 allmodels allmodels allmodels allmodels allmodels

ExteriorLightSwitch 337-20265-00 notavailable 337-20265-00 notavailable 337-20265-00 notavailable

HotGassLoop 315-60307-00 315-60307-00 315-60307-00 315-60310-00

G300:315-60310-00

G320:315-10041-02

315-10041-02

Relay callfactory callfactory callfactory callfactory callfactory callfactory

StartCapacitor callfactory callfactory callfactory callfactory callfactory callfactory

Note:SameGasketsonbothsolidandglassdoors

Note:Fanbladeandmotorbracketarenolongerneeded
