14
INSTALLATION
1.Check if the legs are closely attached to the cabinet. If not, please turn them to
their original positions and tighten the nuts.
2.Loosen the lock nut and turn the feet until it closely contacts with the floor.
3.Adjust the legs and lock them with a spanner, make sure the machine is steady.
Levelling the Washer Dryer
• The lock nuts on all four feet must be screwed tightly against the housing.
Connect Water Inlet Hose
Connect the water inlet hose as indicated, There are two ways to connect the water
inlet hose.
1.Connection between ordinary tap and water inlet hose.
• To prevent leakage or water damage, follow the instructions in this chapter!
• Do not kink, crush, or modify water inlet hose.
2
3
4
1
Raise
Lower
Lock nut
Foot
Warning!
Warning!
Loosen clamp nut and
four bolts
Press the tap end
tightly to the rubber
ring inside the clamp,
and then, tighten the
4 bolts
Press slide bushing,
insert water inlet
hose into connecting
base
Slide bushing
2
3
41
Connection finished
Clamp nut
Tap with threads and water inlet hose
Special tap for washing machine
2.Connection between screw tap and waterinlet hose.
Slide bushing
5mm
