14
INSTALLATION
Levelling the washing machine
Connect Water Inlet Hose
2
3
4
1
Raise
Lower
Lock nut
Foot
Loosen clamp nut and
four bolts
Press the tap end
tightly
to the rubber ring
inside the clamp, and
then, tighten the 4 bolts
Press slide bushing,
insert water inlet hose
into connecting base
Slide bushing
2
3
41
Connection finished
Tap with threads and water inlet hose
Special tap for washing machine
Slide bushing
1. Check if the legs are closely attached to the cabinet. If not, please turn them to
their original positions and tighten the nuts.
2. Loosen the lock nut and turn the feet until it closely contacts with the floor.
3. Adjust the legs and lock them with a spanner, make sure the machine is steady.
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
Connect the water inlet hose as indicated, there are ways to connect the
inlet hose.
three water
1. Connection between ordinary tap and water inlet hose.
• To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush, modify water inlet hose.or
!
Warning!
Clamp nut
5mm
2. Connection between screw tap and water inlet hose.
Slide bushing
2
3
41
3. Connection between ordinary tap and water inlet hose with water filter.
Loosen clamp nut and
four bolts
Press the tap end
to the rubber ring
inside the clamp, and
then, tighten the 4 bolts
tightly Press slide bushing,
into connecting base
insert water inlet hose
Connection finished
