EN-17
0 cm
20 cm
30 cm
20 cm
> 85 cm
SIDE
DISTANCE
CM
Top 30cm
Left 20cm
Right 20cm
Behind 0cm
Front Open
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage such as dents or
broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not
remove the waveguide cover that is attached to the oven cavity to protect the magnetron.
INSTALLATION
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
a. The minimum installation height is 85cm.
b. The rear surface of appliance shall be placed against a wall.Leave a minimum clearance of
30cm above the oven. A minimum clearance of 20cm is required between the oven and any
adjacent walls.
c. Do not remove the legs from the bottom of the oven.
d. Blocking the intake and/or outlet openings can damage the oven.
e. Place the oven as far away from radios and TV as possible. Operation of microwave oven may
cause interference to your radio or TV reception.
2. Plug microwave oven into a standard household outlet. Be sure the voltage and the frequency
is the same as the voltage and the frequency on the rating label.
NOTE
• Do not install oven over a range cooktop or
other heat-producing appliance.
If installed near or over a heat source, the
oven could be damaged and the warranty
would be void.
The accessible surface may be
hot during operation
