12
7. Install the replaced freezing door on the lower hinge then install the middle hinge
and cover the hinge hole decorative cover.
8.Remove the upper left hinge cover and upper left hinge from the accessory bag.
Place the refrigerated door body on the middle hinge and install the upper left hinge.
Connect the refrigerator top signal line 4 to the door body signal line 1.
Finally, replace the hinge decorative cover to the right side of the box body (note: when
replacing the hinge decorative cover to the right side of the box body, the two inserts
on the hinge decorative cover (as shown in the figure) shall be cut off ).
Decorative
cover
Middle
hinge
Upper hinge
Upper hinge cover
Decorative cover
Inserts
2
4
1
4
1
2
