10
2. Remove the upper left hinge cover decorative cover, upper right hinge cover and
upper right hinge, and disconnect the right signal line(signal line terminal 1,2) at the
top of the box body.
3.Remove the refrigerated door body (be careful not to lose small parts such as the
shaft sleeve and stop on the door);
Remove the middle hinge and remove the decorative cover of hinge hole on the
other side.
4.Remove the freezing door body (be careful not to lose small parts such as the shaft
sleeve and stop on the door);
Remove the hinge and adjust the angle. Remove and install the lower hinge shaft to
the other side of the hinge, and install the modified lower hinge to the other side of
the box.
upper hinge cover
decorative cover
upper hinge
1
2
Decorative cover
Middle hinge
The angle
Lower hinge
