English - 25 -
• Use the WPS button on your router. Highlight Join
Network Using WPS (Button) option and press
Select. Press the WPS button on your router. Your
TV will connect to your router, without the use of a
password.
Note: During the initial setup process Connect using
WPS Push Button option will be available instead of Join
Network Using WPS (Button) option.
• Enter WPS PIN on your router. Highlight Join
Network Using WPS (PIN) option and press Select.
A code will be created and displayed on the screen.
Enter this code on your router. Your TV will connect
to your router, without the use of a password.
Note: During the initial setup process Connect using WPS
PIN option will be available instead of Join Network Using
WPS (PIN) option.
1
1. Broadband ISP connection
A network with hidden SSID can not be detected by
other devices. If you want to connect to a network
with hidden SSID, highlight the Join Other Network
option under the Network menu and press Select.
Add the network by entering its name, security type
and password manually. If you want to configure
additional settings of the network manually, highlight
Advanced when prompted and press Select. Follow
the on-screen instructions to proceed and enter the
required values respectively.
If you want to save the wireless network passwords
to Amazon you can use the Save Wi-Fi Passwords
to Amazon option. To delete saved passwords turn
this option o.
A Wireless-N router (IEEE 802.11a/b/g/n/ac) with 2.4
and 5 GHz bands is designed to increase bandwidth.
These are optimised for smoother and faster HD video
streaming, le transfers and wireless gaming.
Use a LAN connection for quicker data transfer
between other devices like computers.
The transmission speed diers depending on the
distance and number of obstructions between the
transmission products, the configuration of these
products, the radio wave conditions, the line trac
and the products that you use. The transmission may
also be cut o or may get disconnected depending
on the radio wave conditions, DECT phones or any
other WLAN 11b appliances. The standard values of
the transmission speed are the theoretical maximum
values for the wireless standards. They are not the
actual speeds of data transmission.
The location where the transmission is most eective
diers depending on the usage environment.
The Wireless feature of the TV supports 802.11 a,b,g,n
& ac type modems. It is highly recommended that
you should use the IEEE 802.11ac communication
protocol in order to avoid any possible problems while
watching videos.
You must change your modem’s SSID when there are
any other modems around with the same SSID. You
can encounter connection problems otherwise. Use a
wired connection if you experience problems with a
wireless connection.
A stable connection speed is required to play back
streaming content. Use an Ethernet connection if the
wireless LAN speed is unstable.
Wireless LAN Transmitter
Specifications
Frequency Ranges
Max Output
Power
2400 - 2483.5 MHz (CH1 - CH13) < 100 mW
5150 - 5250 MHz (CH36 - CH48) < 200 mW
5250 - 5350 MHz (CH52 - CH64) < 200 mW
5470 - 5725 MHz (CH100 - CH140) < 200 mW
Country Restrictions
The Wireless LAN equipment is intended for home
and oce use in all EU countries, the UK and Northern
Ireland (and other countries following the relevant EU
and/or UK directive). The 5.15 - 5.35 GHz band is
restricted to indoor operations only in the EU countries,
in the UK and Northern Ireland (and other countries
following the relevant EU and/or UK directive). Public
use is subject to general authorisation by the respective
service provider.
Country Restriction
Russian Federation Indoor use only
The requirements for any country may change at any
time. It’s recommended that user checks with local
authorities for the current status of their national reg-
ulations for both 2.4 GHz and 5 GHz wireless LAN’s.
