Figure110

1.Hydraulic-pressurelter

5.Discardtheoldlter.

6.Applyathinlayerofhydraulicoiltotheo-ringofthe

lter.

7.Installandtightenthenewlterwithalterwrench.

8.Starttheengine,letitrunidleforapproximately

1minute,thencheckforleaksaroundthe

hydraulic-pressurelter.

ChangingtheHydraulicFluid

ServiceInterval:Every1,000hours/Yearly(whichever

comesrst)

Important:Iftheuidbecomescontaminated,contact

yourAuthorizedToroDealer,becausethesystemmust

beushed.Contaminateduidlooksmilkyorblack

whencomparedtocleanoil.

Important:Useofanyotherltermayvoidthewarranty

onsomecomponents.

1.Parkthemachineonalevelsurface,stoptheengine,

andremovetheignitionkey.

2.Openthefronthood.

3.Raisethemachineusingproperequipment.

WARNING

Raisingtherearoftheunitrelyingsolely

onmechanicalorhydraulicjackscouldbe

dangerous.Themechanicalorhydraulic

jacksmaynotbeenoughsupportormay

malfunctionallowingtheunittofall,which

couldcauseinjuryordeath.

Do not

relysolelyonmechanicalorhydraulic

jacksforsupport.

Useadequatejackstandsorequivalent

support.

4.Placealargedrainingcontainerunderthehydraulic

uidtank.

5.Removethedrainplugfromthebottomofthetank.

6.Cleanthethreadsonthedrainplugandapply3layers

ofPTFEsealingtape.

7.Drainthehydraulicuidowintothecontainer.

Important:Thecapacityofthehydraulic-uid

tankis102L(27USgallons),soensurethatyou

haveacontainerofatleast114L(30USgallons)

todraintheuidinto.

8.Installthedrainplugwhenthehydraulicuidstops

draining.

9.Cleantheareaaroundtheltermountingareas.

10.Placeadrainpanunderthelterandremovethelter

(Figure109).

11.Lubricatetheltergasketofeachnewlterandll

themwithhydraulicuid.

12.Ensurethattheltermountingareasareclean.

13.Screwtheltersonuntilthegasketscontactsthe

mountingplates;thentightenthelteranadditional

1/2turn.

14.Fillthereservoirwithhydraulicuid.

Important:Useonlythehydraulicuids

specied.Otheruidscouldcausesystem

damage.

15.Installthereservoircap.Starttheengineanduseall

ofthehydrauliccontrolstodistributehydraulicuid

throughoutthesystem.Alsocheckforleaks;thenstop

theengine.

16.Checktheuidlevelandaddenoughtoraiselevelthe

leveltotheFullmarkonthedipstick.Donotoverll.
