Figure80

1.Air-cleanercover2.Filterhousing

8.Cleananydebrisfrominsidethecover.

Important:If“CheckAirFilter”isnotdisplayed

onthescreen,donotremovetheairlters.

InstallingtheAir-CleanerCover

1.Parkthemachineonalevelsurface,stoptheengine,

andremovetheignitionkey.

2.Alignthedustcapontheaircleanerltercovertothe

5o’clockposition.

3.Aligntheaircleanerltercoverwiththelterhousing

(Figure80).

4.Rotatetheaircleanerltercoverclockwise,sothatthe

dustcapisatthe4o’clockposition(Figure79).

5.Pushthelatchontheaircleanerltercoverinward

untilitisfullyseated(Figure79).

ServicingtheAir-CleanerFilter

ServiceInterval:Every250hours

Replacetheltersonlywhenthe“CheckAirFilter”

indicatorappearsonthedisplayscreen;referto

CheckingtheAir-CleanerIndicator(page64).

Note:ContactyourAuthorizedToroDealertoorder

replacementlters.

1.Parkthemachineonalevelsurface,stoptheengine,

andremovetheignitionkey.

2.Openthefronthood.

3.Beforeremovingthelter,cleanoutalldebrisfrom

theinsideofthelterbodyusinglow-pressureair(40

psi,cleananddry).

Important:Avoidusinghighpressureairwhich

couldforcedirtthroughthelterintotheintake

tract.Thiscleaningprocesspreventsdebrisfrom

migratingintotheintakewhentheprimarylter

isremoved.

4.Removetheprimarylter(Figure81).

Important:Donotcleantheusedlter.

1

2

3

4

G022176

Figure81

1.Rubber-outletvalve

3.Air-cleaner,primarylter

2.Air-cleanerlatch4.Air-cleanerbody

5.Inspectthenewlterforshippingdamage,checking

thesealingendofthelterandthebody.Donotuse

adamagedelement.

Important:Donotcleantheusedsafetylter

(Figure82).Replacethesafetylterwithanew

oneafterevery3primarylterservices,orwhen

indicatedbythe“CheckAirFilter”onthedisplay

screen.Ifyouarenotreplacingit,donotremove

thesafetylter.

65
