Figure45

1.Rearstabilizers

6.Pressthe2rightstakeleversintolowerandspinthe

rightstakeaugeruntilitseatsfully(Figure46).

g021835

1

2

3 4

Figure46

1.Left-stake-raise/lower

lever

3.Right-stake-raise/lower

lever

2.Left-stake-spinlever

4.Right-stake-spinlever

7.Repeatstep6fortheleft-sidestake.

ConnectingtoaDrilling-FluidSource

Whendrillingandreaming,youpumpamixtureofbentonite

clay,water,andsometimesotheringredients,collectively

calleddrillinguidor“Mud”,throughthepipeandintothe

bore.Thisdrillinguid,or“Mud”,doesthefollowingfor

yourbore:

•Lubricatesthedrillhead

•Loosensthesoilintowhichthedrilliscutting

•Penetratesandbindsloosesoiltokeepthemfrom

collapsingontheborepipe.

Thespecicmixtureyouneedwillvarydependingonyour

soiltypeandtheoperationyouareperforming;refertoyour

mixingsystemOperator’sManualfordetails.

Conversely,forsomejobs(dependingonthesoiltypeand

distance),youcanpumpscreenedwaterfromanaturalwater

source,suchasalakeorriver,throughthedrillinlieuof

mixeddrillinguid.

•Toconnectthemachinetoamixingsystem,referto

SettingUptheMixingSystem(page48).

•Toconnectthemachinetoanaturalwatersource,referto

SettingUpthePumptoUseaNaturalWaterSource(page

49).

SettingUptheMixingSystem

Setupyourmixingsystemnearthedirectionaldrilllocation,

preferablydownwindsofumesfromthemixingsystem

enginewillnotbotheryouwhiledrilling.Followthe

instructionsprovidedinthemixingsystemOperator’sManual

forsettingitupandusingit.

Completethefollowingtoconnecttheexithosefromthe

mixingsystemtothedrilling-uidpumponthemachine:

1.Raisethecam-lockleversonthepump-inletcapand

removethecap(Figure47).

Figure47

1.Cam-locklevers

2.Pump-inletcap

2.Insertthehosefromthemixingsystemoverthepump

inletandsecureitwiththecam-locklevers.

48
