Giventheaboveinformation,youcancalculatethenumberof

rodsrequiredtoreachyourbeginningpointattheappropriate

depth.Tororecommendsthatyoustarttheentrypointa

distancebackfromyourbeginning-at-depthpointbythe

samedistanceasthelengthofpipesyouwillneedtoreach

thatpoint.Thiswillensurethatyouhaveenoughextraspace

soyouwillnotneedtoover-steeranddamagethepipes.

Thefollowingexampleillustratestheprocessgivenan

installationusingthemaximumentrypitchofthemachine

(26%)onlevelground:

•Youinserttherst3m(10ft)ofdrillbit/pipeintothe

groundwithnosteering.Theendofthedrillbitwillbe

76cm(30inches)deep(Figure25).

1

4

2

3

5

g021768

7

6

Figure28

1.26%pitch4.185cm(73inches)7.14.7m(45ft)

2.76cm(30inches)5.203cm(80inches)

3.142cm(56inches)6.208cm(82inches)

•Youbeginsteeringupforthenext3m(10ft),pushingthe

pipesinatthemaximumpitchchangeof8%.Thisresults

inachangeofpitchfrom26%atthebeginningofthe3m

(10ft)to18%attheendofthe3m(10ft)foranaverage

pitchof22%.Giventhat,thedrillheadlowersanother66

cm(26inches)andisnow142cm(56inches)deep.

•Continuingsteeringupforthenext3m(10ft)atan8%

pitchchange,yourpitchwillchangefrom18%to10%

foranaveragepitchof14%.Giventhat,thedrillhead

lowersanother43cm(17inches)andisnow185cm(73

inches)deep.

•Continuingsteeringupforthenext3m(10ft)atan8%

pitchchange,yourpitchwillchangefrom10%to2%for

anaveragepitchof6%.Giventhat,thedrillheadlowers

another18cm(7inches)andisnow203cm(80inches)

deep.

•Levelingthedrillheadfrom2%to0%takeslessthan1.5

m(5ft)moreforanaldepthof208cm(82inches).

Reachingthisnalpointtookfourandahalf,3m(10ft)

pipes.Soforthisexampleyourentrypointshouldbe

14.7m(45ft)backfromthebeginning-at-depthpointof

yourinstallation.

37
