8
SPECIFICATIONS
Features
Max hot water temp.
Wash
tub
Spin
tub
220 V, 50 Hz
two ways vortex system
two ways (Heavy-Gentle)
Wind up Spring type
(15 min.wash / 30 min.soak)
56 L
centrifugal extraction system
spin tub 50HZ:1200 r.p.m
wind up spring type 5 min
910 x 775 x 438 mm
TWH-Z07DNEP-W :19.5
TWH-Z07DNEP-W: 18.5
220 V, 50 Hz
two ways vortex system
two ways (Heavy-Gentle)
Wind up Spring type
(15 min.wash / 30 min.soak)
76 L
centrifugal extraction system
spin tub 50 HZ:1200 r.p.m
wind up spring type 5 min
960 x 825 x 470 mm
TWH-Z10DNEP-W :22
TWH-Z10DNE-W: 21
220 V, 50 Hz
two ways vortex system
two ways (Heavy-Gentle)
Wind up Spring type
(15 min.wash / 30 min.soak)
high : 89 L , low : 65 L
centrifugal extraction system
spin tub 50 HZ: 1200 r.p.m
wind up spring type 5 min
970 x 865 x 500 mm
TWH-Z12DNEP-W :22
TWH-Z12DNE-W: 21
- wash mode selector - water feed selector
- direction free lint filter - soak - antibacterial pulsator
washing system
washing speed
timer
water level
dehydrayion system
revolution
timer
SPECIFICATIONS
No.
Power source
Total power
consumption
Washing power consumption
Spin power consumption
1
2
3
4
5
6
7
8
Overall dimensions (mm)
Net weight
50
O
C
TWH-Z07DNE-W
TWH-Z07DNEP-W
TWH-Z10DNE-W
TWH-Z10DNEP-W
TWH-Z12DNE-W
TWH-Z12DNEP-W
370 watt
150 watt
380 watt
150 watt
400 watt
150 watt
ﺔﻴﺑﺮﻬﻜﻟا ةﺮﺋاﺪﻟا
Electrical circuit
TWH-Z07DNEP-W
TWH-Z10DNEP-W
TWH-Z12DNEP-W
ﻞﻳدﻮﻤﻠﻟ
TWH-Z07DNE-W
TWH-Z10DNE-W
TWH-Z12DNE-W
ﻞﻳدﻮﻤﻠﻟ
- Drain With Pump For Models: TWH-Z07DNEP-W & TWH-Z10DNEP-W & TWH-Z12DNEP-W
Fuse
Yellow
Yellow/Green
Red
Red /White
Orange
Brown
Brown
Brown
GrayC2
Spin Motor
Wash Motor
Drain pump
Drain switch
Spin Timer
Wash Timer
Safety Switch
Blue
Blue
Blue
Blue
Purple
Purple
S2
a
b
C1
S
1
S3
Electric Wire Diagram Electric Wire Diagram
