2
LIFE TIME
TMH-HS07C & TMH-HS10C & TMH-HS12C & TMH-HS07CP & TMH-HS10CP & TMH-HS12CP
ELARABY is committed to provide maintenance and
spare parts after the warranty period by a cost and this
for 2 year.
OUTLET OF THE DRAIN HOSE
When the drain hose outlet is exchanged to left
side of the machine:
1- Push down and remove the drain hose from the
hose hook on the lower end of the machine.
2- Push up the drain hose and hold it into the other
hose hook.
- Do not put the drain hose end in the drainage ditch.
- The drain hose should be laid flat on the ground, water
flow will be restricted if any portion of the drain hose is
raised more than 15 cm (6 in) from the ground.
- After changing the drain hose, make sure that the
hose is not loose.
- Do not push the drain hose into the cabinet.
- The length of the drain hose may be extended to as
much as 1.5 m if kept level.
- Install the machine on a stable and
level place.
)
يضارتفا رمعلا
Lint Filter
Catch the lint in the wash tub
(TWH-Z12DNE-W)
Wash tub LidDrain Valve Knob & Wash Selector Heavy or gentle
wash mode
Wash Timer Knob
to the fabric
Water Feed Selector :
you can select the water feed to
the wash tub or to the spin basket
Drain hose
Water inlet
spin Tub Lid When you open this lid while
the spin basket is rotating ,the brake will
Inner Lid : Don not touch the spin
basket while rotating
Spin Basket
TMH-HS07C
TMH-HS10C
TMH-HS07CP
TMH-HS10CP
TMH-HS12C
TMH-HS12CP
Rinse Water Level Control
Cabinet Base
Caution
Drain hose
PUMP DRAIN
Hose
clamp
1.5 m or less
15 cm
or less
