7
INSTALLATION
OPERATION
20cm
30cm
20cm
min85cm
0cm
Countertop Installation
Remove all packing material and accessories. Examine the oven for any damage such
as dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to protect
the magnetron.
1.Select a level surface that provide enough
open space for the intake and/or outlet vents.
(1) The minimum installation height is 85cm.
(2) The rear surface of appliance shall be
placed against a wall.
Leave a minimum clearance of 30cm above
the oven, a minimum clearance of 20cm is
required between the oven and any adjacent walls.
(3) Do not remove the legs from the bottom of the oven.
(4) Blocking the intake and/ or outlet openings can damage the oven.
(5) Place the oven as far away from radios and TV as possible. Operation of microwave
oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet.
Be sure the voltage and the frequency is the same as the voltage and the frequency
on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing
appliance.
If installed nea or over a heat sourc oven could be damaged and the
warranty would be void.
The accessible surface may be hot during operation.
1. Power Level
11 power levels are available
Level 10 9 8 7 6 5 4 3 2 1 0
Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0%
Display PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1 PL0
2. Clock Setting
(1) Press “ CLOCK “, “00:00” will display.
(2) Press the number keys and enter the current time. For example, time is 12:10 now,
please press “1,2,1,0” in turn.
SETTING UP YOUR OVEN
