No. Part No. Description Qty

1 X9003 Defoamer Warning Label 1

2 X8295 Screw, #8 x 3/4” 6

3 PX103A Screw-In Lid 4” w/Black Ring 1

4 X9061 Shut Off Disk 1

5 X9087 Washer 1

6 X9088 Screw 8-18 x 1/2” 1

7 PX103AG Lid Gasket 1

8 X9518 Deﬂector 1

9 X9062 Float 1

10 X9082-KIT Stand Pipe Sub-Assembly 1

11 X2046-YEL Tornado Label 2

12 X9999 Hose Assembly 1

13 7DL003 Hose Clamp 4

14 PX46 Lock Nut 1

15 X9079 Gasket 1

16 X2045 Fill Label 1

17 X1920BLK Solution Tank 1

18 PC66 Hose Barb 1/4”H x 1/8MPT 1

19 71817A Hose, 1/4” 250 PSI 8

20 X9740 Gasket 1

21 X8237 Nyloc Nut 3

22 X9060 Vacuum Motor Screen 1

23 1942-B Vacuum Motor 2 Stage 1

24 X9045 Spacer 3

25 7CY001 Internal Tooth #10 Lock Washer 1

26 X9214 Ground Symbol Label 1

27 PC10 QD Male 1/8” x 1/8” NPT 1

28 X9412 Washer 1

29 7AT006 Brass 90° Elbow Fitting 1/4” Barb x 1/8” MPT 1

30 X8212 Lock Washer 7

31 X8291 Screw 1/4-20 x 5-1/2” 3

32 X9047 Swivel Caster 45mm 1/4-20 x 3/4” 2

33 X8459 Serial Number Label 1

34 7BS003 Screw 1/4-20 x 1/2” 2

35 00-0600-0503 Washer 8

36 30676 Screw 10-24 x 5/8” 5

37 X9046 Base Plate Weldment 1

PART LIST
