PARTS LIST
No.
Description Qty.
No.
Description Qty.
1 Computer 1 33 Limiter 1
2 Computer holder 1 34 Rubber φ11*φ8*3 1
3 Bolt M5*25 4 35 Horizontal Saddle Tube 1
4 Cap Nut M8*H16*S13 1 36 Fixed Plate of Horizontal saddle tube 1
5
Washer d8*φ20*2
7 37 Saddle Tube 1
6 Computer Post 1 38 Bolt Φ8*30 2
7 Bolt M8*35*S6 1 39 Bearing 608ZZ 4
8 End cap 1 40 Roller Φ71*Φ19*24 2
9 Foam Grip 2 41 Washer d6*Φ12*1.5 2
10 End cap φ28*17 2 42 Bolt M6*12*S5 2
11 Bolt M10*25*S8 2 43 Bolt M8*20*S6 4
12 Spring Washer d8 2 44 End Cap J50*70 4
13 Washer d10*φ20*2 4 45 Front Stabilizer 1
14
Handlebar Join
1
46
Nut M8
4
15
Knob
1
47
Adjustable Footpad
4
16 Horizontal handlebar tube 1 48 Rear Stabilizer 1
17 End Cap J40*20*17 4 49 L/R Pedal 1
18 Bolt M5*18 12 50 Main Frame 1
19 Lower sliding plate 2 51 Knob 1
20 Rubber plate 2 52 Screw ST4.2*16*Φ8 2
21
Fixed Plate of Horizontal handlebar tube
1 53 Plug plate 1
22 Handlebar Tube Join 1 54 Screw ST3*12 6
23 Spring washer d8 6 55 Cover For Flywheel 2
24 Bolt M8*16*S6 2 56 Nut M12*1 4
25 L type Handle M16*1.5 1 57 Wave Washer d12*Φ15.5*0.3 2
26 Saddle 1 58 Spacer Φ18*Φ12.1*12.5 1
27 Nylon nut M6*H6*S10 7 59 Nut M12*1*H6*S19 2
28 Washer d6*φ12*1 1 60 Bearing 6201-ZZ 2
29
Handlebar Of Horizontal Saddle
Tube
1 61 Flywheel 1
30 Locking Core 1 62 Flywheel shaft 1
31 Limiter Pin φ3*20 1 63 Screw ST3*16 8
32 Bolt M4*12 2 64 Bushing 4
