Toorx ERX550 handleiding
Handleiding
Je bekijkt pagina 5 van 24
No.
Description
Qty.
No.
Description
Qty.
1
Computer
1
30
Wave washer d19*Ф25*0.3
4
2
Washer d4
4
31
Bushing Φ27*1*Φ19.2*16
4
3
Bolt M4
4
32
Bushing Φ50*Φ21*20
4
4
Middle handlebar
1
33
Washer d8*Φ32*2
2
5
Grip foam
2
34
Handlebar cover
2
6
Handle pulse plate
2
35
Screw ST4.2*13
4
7
Screw ST4.2*19
2
36L/R
Swing bar cover L/R
2
8
End cap ф25*26
2
37
End cap PT50*25
4
9
Handle pulse wire
2
38L/R
Linkage L/R
1
10
Washer d8*Φ20*2
14
39
Bolt Φ10*34*M6*15*S6
2
11
Spring washerd8
17
40
Bushing Φ18*1.5*Φ14.6*5*Φ10.1
4
12
Bolt M8*20*S5
19
41
Washer d6*Φ16*1.5
3
13
Cover
1
42
Bolt M6*15*S5
2
14
Handlebar post
1
43
End cap J60*30*15
2
15
Bolt M8*25*S13
4
44
Pedal
2
16L/R
Handlebar post cover
1
45
Cover
2
17
Supporter
1
46
Washer d8*Φ25*2
11
18
Screw ST4.2*16
21
47
Bearing R12
4
19
Screw ST4.2*19
25
48
Bushing Φ60*16.6Φ41.18*13.11
4
20
Main frame
1
49
Bolt M8*50*20*S14
2
21
End cap
2
50
Connector
2
22L/R
Handlebar L/R
1
51
Cover
4
23
Grip foam
2
52
Shaft
2
24
Handlebar cover
2
53
Bushing Φ32*3.3*Φ28*20.5*Φ19.1
4
25L/R
Reciprocating bar L/R
1
54L/R
Linkage
1
26
Nylon nut M8*H7.5*S13
8
55
Spacer φ22*φ16*3
4
27
Arc washerd8*Φ20*2*R16
4
56
Shaft for transportation wheel
2
28
Bolt M8*40*15*S5
4
57
Screw ST4.2*8
4
29
Spacer Φ30*19*9
2
58
Roller
2
No.
Description
Qty.
No.
Description
Qty.
59
Wheel cover
2
86
Magnet
7
60
Front stabilizer
1
87
Bolt M6*65*S10
1
61
End cap L/R
1
88
Spring
1
